APC SMX3KR2UNCX145 - UPS - RACK-MOUNTABLE - LINE-INTERACTIVE - 120 V - 2700WATT - NE

This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 3kVA line interactive 2U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with NEMA L5-30P input, 3x NEMA 5-15R, 3x NEMA 5-20R and 1x NEMA L5-30R outlets. The UPS has a preinstalled Network Management Card for UPS network-based monitoring and management. The Smart-UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms. The SMX UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. This is compatible with dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. The Smart-UPS comes with a pair of tower-mounting stabilizing feet and rack-mounting brackets. It comes with APC temperature sensor AP9335T for monitoring temperature. The 3 switchable outlet groups allow more granular management of the power supplied to your devices. The Emergency Power Off feature enables the UPS to remotely shutdown during emergencies.

General Information
Manufacturer	Schneider Electric SA
Manufacturer Part Number	SMX3KR2UNCX145
Manufacturer Website Address	http://www.schneider-electric.com
Brand Name	APC by Schneider Electric
Product Line	Smart-UPS X
Product Name	Smart-UPS X 3000VA Tower/Rack Convertible UPS
Packaged Quantity	1
Product Type	Line-interactive UPS
Technical Information
Plug/Connector Type	NEMA L5-30P
Receptacle Type	NEMA L5-30P
Receptacle Detail	3 x NEMA 5-20R
Receptacle Detail	3 x NEMA 5-15R
Receptacle Detail	1 x NEMA L5-30R
Number of Battery & Surge Outlets	7
Cord Length	10 ft
Transfer Time	4 ms
Phase	Single Phase
Application/Usage	Switch
Application/Usage	POS
Application/Usage	Hub
Application/Usage	Network Device
Application/Usage	Server
Application/Usage	Router
Power Description
Load Capacity (VA)	2880 VA
Load Capacity (Watt)	2700 W
Input Voltage	120 V AC
Input Voltage Range	70 V AC - 153 V AC
Input Current	15 A
Output Voltage	120 V AC
Input Frequency	60 Hz
Output Frequency	60 Hz
Waveform Type	Sine Wave
Surge Energy Rating	540 J
Management
Alarm	Low Battery
Alarm	Configurable Delay
Alarm	On Battery
Controls/Indicators
Status Indicators	LED: On Line On Battery Replace Battery Overload Indicators
Interfaces/Ports
EPO Port	Yes
USB (HID Compliant) Port	No
Battery Information
Battery Chemistry	Lead Acid
Battery Life	5 Year
Typical Battery Recharge Time	3 Hour
Environmental Conditions
Maximum Operating Temperature	104°F (40°C)
Storage Temperature	5°F (-15°C) - 113°F (45°C)
Maximum Operating Elevation	10000 ft
Maximum Storage Elevation	50000 ft
Storage Relative Humidity	0% - 95%
Sound Emission (A-Weighted)	55 dB(A)
Thermal Dissipation	80.89 W
Physical Characteristics
Color Family	Black
Product Color	Black
Height	3.3"
Width	17"
Depth	26.3"
Rack Height	2U
Form Factor	Tower/Rack Convertible
Mounting Preference	Lower
Mounting Location	Front
Weight (Approximate)	84.59 lb
Miscellaneous
For Country/Region	United States
Package Contents	Smart-UPS X 3000VA Tower/Rack Convertible UPS CD With Software Documentation CD Installation Guide Rack Mounting Hardware Rack Mounting Brackets Rack Mounting Support Rails Removable Support Feet Smart UPS Signalling RS-232 Cable USB Cable Web/SNMP Management Card
Certifications & Standards	BSMI|CSA|NOM|TÜV|VCCI Class A
Product Take Back Program	Yes
Mercury Free	Yes
RoHS Exemption Information	https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SMX3KR2UNCX145_ROHS_DECLARATION&p_FileName=SMX3KR2UNCX145KIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL	https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=557301549&lang=en-us
EU RoHS Declaration URL	https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=557301549&lang=en-us
Environmental Profile Availability	https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612029_EN
End of Life Manual Availability	https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612029_EN
REACH free of SVHC	No
WEEE Statement	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Environmental Compliance	Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
Limited Warranty	3 Year
Additional Warranty Information	UPS: 36 month(s)|Battery: 24 month(s)
Directly Connected Equipment Guarantee	$150000 Lifetime
