The EDS8PS Device Server are unique, hybrid Ethernet terminal/multiport device servers which allow remote access to and management of virtually any IT/networking equipment or edge device like medical equipment, POS terminals or security equipment.
Featuring Lantronix' powerful Evolution OS, EDS delivers an unprecedented level of intelligence and safety. With AES, SSH and SSL built in, EDS provides enterprise-level security allowing safe remote access and management from practically anywhere.
General Information | |
Manufacturer | Lantronix, Inc |
Manufacturer Part Number | EDS008PS-02 |
Manufacturer Website Address | http://www.lantronix.com |
Brand Name | Lantronix |
Product Model | EDS8PS |
Product Name | EDS8PS Device Server |
Product Type | Device Server |
Media & Performance | |
Media Type Supported | Twisted Pair |
Network & Communication | |
Ethernet Technology | Fast Ethernet |
Network Standard | 10/100Base-TX |
Interfaces/Ports | |
Network (RJ-45) | Yes |
Number of Network (RJ-45) Ports | 1 |
Physical Characteristics | |
Form Factor | Desktop |
Height | 1.7" |
Width | 8.9" |
Depth | 5" |
Weight (Approximate) | 1.10 lb |
Miscellaneous | |
Environmentally Friendly | Yes |
Warranty | |
Limited Warranty | 2 Year |
Mechanical | |
Dimensions: WxHxD (mm) | 128 x 227 x 43 |
Mounting | Wall Mount |
Enclosure | - |
Interface | |
Serial interface | RS232 |
Serial interface number of ports | 8 |
Serial Interface type of connector | RJ45 |
Network interface | 1 Port Ethernet RJ45 Connector |
Network interface number of ports | 1 |
Network interface type of connector | RJ45 |
Power | |
Power Input Type | Single AC / Plug |
Operating Supply Voltage | 100 to 240 VAC |
Power Consumption | 20W |
Reliability | |
Operating Temperature | 0 to 55C |
Isolation Protection | - |
Surge Protection | - |
Standards and Certifications | Safety UL 60950-1, EN 60950-1, EMC CE, FCC, EMI EN 55022 Class A, FCC Part 15 Subpart B Class A, EMS EN 55024 |
Device Type | Device server |
Width | 8.9 in |
Depth | 5 in |
Height | 1.7 in |
Processor / Memory / Storage | |
Processors Installed | 1 x Intel IXP420 266 MHz |
Max Supported Qty | 1 |
RAM Installed ( Max ) | 64 MB SDRAM |
Flash Memory Installed (Max) | 8 MB flash |
Networking | |
Form Factor | External |
Ports Qty | 8 |
Connectivity Technology | Wired |
Data Link Protocol | Ethernet, Fast Ethernet, RS-232 |
Network / Transport Protocol | TCP/IP, UDP/IP, ICMP/IP, LPR/LPD, ARP, SMTP, FTP, BOOTP, DHCP, DNS |
Remote Management Protocol | SNMP 2, Telnet, HTTP, HTTPS, SSH-2 |
Status Indicators | Link activity, power, transmit, receive |
Features | DHCP support, ARP support, IP address filtering |
Encryption Algorithm | AES, SSL 3.0, 128-bit AES |
Authentication Method | Secure Shell v.2 (SSH2) |
Compliant Standards | IEEE 802.3, IEEE 802.3u |
Expansion / Connectivity | |
Interfaces | 8 x serial - RS-232 - RJ-45 1 x network - Ethernet 10Base-T/100Base-TX - RJ-45 1 x management - RJ-45 |
Miscellaneous | |
Compliant Standards | CE, VCCI, C-Tick, EN55022, ICES-003, EN55024, EN55022 Class A, FCC Part 15 B, UL 60950-1, CSA C22.2 No. 60950-1-03 |
Power | |
Power Device | Power supply - internal |
Voltage Required | AC 120/230 V ( 50/60 Hz ) |
Power Consumption Operational | 20 Watt |
Software / System Requirements | |
OS Required | Microsoft Windows 98/ME/NT/2000/XP |
Manufacturer Warranty | |
Service & Support | 2 years warranty |
Service & Support Details | Limited warranty - 2 years |
Environmental Parameters | |
Min Operating Temperature | 32 °F |
Max Operating Temperature | 131 °F |
Humidity Range Operating | 5 - 95% |
