STARTECH
SV431DUSB StarTech.com 4 Port 1U Rackmount USB PS/2 KVM Switch with OSD
Mfg Part Number: SV431DUSB , Item #: 546290
, PO and Wire.
This 4-port USB+PS/2 KVM Switch lets you control multiple PS/2 or USB-controlled computers from a single console (USB keyboard, USB mouse, monitor).
The versatile USB PS/2 KVM switch features convenient pushbutton and hot-key control for quick, reliable switching between connected computers.
A convenient and straight-forward control solution, the USB PS/2 KVM switch supports both manual and auto-scan modes and simple configuration through the built-in OSD.
Designed to ensure maximum space-efficiency, the USB+PS/2 KVM switch features a slim 1U design that fits neatly into a server equipment rack/cabinet and offers rear cable connections to eliminate cable tangles.
Rackmount your KVM switch
If you'd like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket(sold separately) that turns this KVM into a rackmountable KVM.
The SV431DUSB onlyworks with specific 2-in-1 VGA and USB cables (soldseparately), a list ofStarTech.com approved cables are below:
6ft Ultra Thin USB VGA 2-in-1 KVM Cable 6ft Ultra Thin USB VGA 2-in-1 KVM Cable 10 ft Ultra Thin USB VGA 2-in-1 KVM Cable 15ft Ultra Thin USB VGA 2-in-1 KVM Cable
This product is TAA compliant and is backed by a Startech.com 3 year warranty with lifetine technical support.
More from the Manufacturer
| General Information | |
| Manufacturer | StarTech.com |
| Manufacturer Part Number | SV431DUSB |
| Manufacturer Website Address | http://www.startech.com |
| Brand Name | StarTech.com |
| Product Name | 4 Port 1U Rackmount USB PS/2 KVM Switch with OSD |
| Packaged Quantity | 1 |
| Product Type | KVM Switchbox |
| Technical Information | |
| Number of Computers Supported | 4 |
| Number of Local Users Supported | 1 |
| Daisy Chain Supported | Yes |
| Video | |
| Maximum Video Resolution | 1920 x 1440 |
| Interfaces/Ports | |
| USB | Yes |
| VGA | Yes |
| Number of USB Ports | 2 |
| Number of VGA Ports | 5 |
| Power Description | |
| Input Voltage | 9 V DC |
| Input Voltage Range | 110V AC to 240V AC |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Desktop |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Height | 1.7" |
| Width | 5.1" |
| Depth | 8.7" |
| Weight (Approximate) | 3.31 lb |
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
- Optional rack-mountable bracket
- Powerful features that increase usability
- Ultra-compatible
- Unparalleled reliability
- A dependable 3-year warranty provides peace of mind
- Auto-scan function automatically selects computer sequentially
- Hotkey functions allow easy computer access
- Identifies and selects computers by the names assign
- Keyboard and mouse console is USB interface
- OSD security option allows certain PCs to be password protected from unauthorized use
- Plug-and-play system configuration
- Rugged, all-metal 1U chassis for use in harsh environments and space-saving cabinets
- Supports PS/2 keyboards and mouse including M/S IntelliMouse (Pro), Explorer and Optical mice
- Unique cables for secured connection
- Co-location/ISP computer control
- Datacenter computer control
- Manufacturing line computer control
- PC test/burn-in computer control
- Server farms
| Warranty | 3 Year |
| Product Height | 1.69 in [43 mm] |
| KVM Audio | No |
| KVM Cascadable | No |
| KVM Interface | USB |
| KVM IP Control | No |
| Number of KVM Ports | 4 |
| KVM Rackmount | Yes |
| Product Length | 8.66 in [220 mm] |
| Power Adapter Included | Yes |
| Power Adapter - Amperage | 0.5 |
| Power Adapter - DC Voltage | 9 |
| Power Adapter Center Tip Polarity | Positive |
| Carton Quantity | 6 |
| Product Width | 5.12 in [130 mm] |
| Temp Operating | 5 ~ 40 C |
| Temp Storage | -20 ~ 60 C (0-80% Humidity) |
| Interface Compatibility | For UCNV series they can support SUN keyboard emulation |
| Operating System | Operating system independent and transparent to all applications |
