The Lenovo ThinkSystem SR650 V3 is an ideal 2-socket 2U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR650 V3 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.
| General Information | |
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 7D76A07LNA |
| Manufacturer Website Address | http://www.lenovo.com/us/en/ |
| Brand Name | Lenovo |
| Product Line | ThinkSystem |
| Product Series | SR650 V3 |
| Product Model | 7D76A07LNA |
| Product Name | ThinkSystem SR650 V3 7D76A07LNA Server |
| Product Type | Server |
| Processor | |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 1 |
| Processor Type | Xeon Silver |
| Processor Generation | 5th Gen |
| Processor Model | 4509Y |
| Processor Core | Octa-core (8 Core) |
| Processor Speed | 2.60 GHz |
| Cache | 22.50 MB |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C741 |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 8 TB |
| Memory Technology | TruDDR5 |
| Memory Clock Speed | 4.80 GHz |
| Error Checking | ECC |
| Total Number of Memory Slots | 32 |
| Number of Occupied Memory Slots | 1 |
| Intel Optane Memory Ready | Yes |
| Signal Processing | Registered (Buffered) |
| Controllers | |
| Controller Type | 12Gb/s SAS |
| Controller Model | 940-8i 4GB |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 6, 10, 50, 60 |
| I/O Expansions | |
| Number of Total Expansion Bays | 8 |
| Number of Internal 2.5" Bays | 8 |
| Number of SFF Bays | 8 |
| Hot Swappable Bays | Yes |
| Total Number of Expansion Slots | 3 |
| PCI Express Details | 3 (x16, x8, x8) Gen5 |
| Display & Graphics | |
| Graphics Controller Model | AST2600 |
| Graphics Memory Capacity | 16 MB |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| Number of USB 2.0 Ports | 1 |
| Network (RJ-45) | Yes |
| VGA | Yes |
| Number of VGA Ports | 2 |
| Remote Management | Yes |
| Remote Management Controller | XClarity Controller 2 (XCC2) Standard |
| Operating System | |
| Operating System Supported | Red Hat Enterprise Linux 9.4 |
| Operating System Supported | Windows 11 Pro x64 |
| Operating System Supported | SUSE Linux Enterprise Server 15 SP4 |
| Operating System Supported | Red Hat Enterprise Linux 9.1 |
| Operating System Supported | Ubuntu 24.04 LTS x64 |
| Operating System Supported | Red Hat Enterprise Linux 9.3 |
| Operating System Supported | Red Hat Enterprise Linux 9.2 |
| Operating System Supported | Red Hat Enterprise Linux 8.8 |
| Operating System Supported | Windows Server 2022 |
| Operating System Supported | Windows Server 2019 |
| Operating System Supported | Red Hat Enterprise Linux 8.9 |
| Operating System Supported | SUSE Linux Enterprise Server 15 SP5 |
| Operating System Supported | Red Hat Enterprise Linux 8.6 |
| Operating System Supported | Ubuntu 22.04 LTS x64 |
| Operating System Supported | Windows 10 Pro x64 |
| Operating System Supported | Red Hat Enterprise Linux 9.0 |
| Operating System Supported | Red Hat Enterprise Linux 8.7 |
| Power Description | |
| Input Voltage | 230 V AC |
| Input Voltage | 120 V AC |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 1 |
| Plug/Connector Type | C13 |
| Maximum Power Supply Wattage | 750 W |
| Hot Swappable Power Supply | Yes |
| Power Source | Power Supply |
| Physical Characteristics | |
| Form Factor | Rack |
| Rack Height | 2U |
| Height | 3.4" |
| Width | 17.5" |
| Depth | 30.1" |
| Weight (Approximate) | 85.54 lb |
| Miscellaneous | |
| Package Contents |
|
| Security Features |
|
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Bronze (EPEAT Bronze) |
| Environmental Certification | China Environmental Labeling Program (CELP) |
| Environmental Certification | GREENGUARD |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Energy Efficiency Certification | ENERGY STAR 4.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD). |
