The Lenovo ThinkSystem SR655 is a 1-socket 2U server that features the AMD EPYC 7002 "Rome" and AMD EPYC 7003 "Milan" families of processors. With up to 64 cores per processor and support for the PCIe 4.0 standard for I/O, the SR655 offers the ultimate in single-socket server performance.
General Information | |
Manufacturer | Lenovo Group Limited |
Manufacturer Part Number | 7Z01A05FNA |
Manufacturer Website Address | http://www.lenovo.com/us/en/ |
Brand Name | Lenovo |
Product Line | ThinkSystem |
Product Series | SR655 |
Product Model | 7Z01A05FNA |
Product Name | ThinkSystem SR655 7Z01A05FNA Server |
Product Type | Server |
Processor | |
Number of Processors Supported | 1 |
Number of Processors Installed | 1 |
Processor Type | EPYC |
Processor Generation | 3rd Gen |
Processor Model | 7203P |
Processor Core | Octa-core (8 Core) |
Processor Speed | 2.80 GHz |
Cache | 64 MB |
Chipset | |
Chipset Manufacturer | AMD |
Memory | |
Standard Memory | 32 GB |
Maximum Memory Supported | 2 TB |
Memory Technology | TruDDR4 |
Memory Clock Speed | 3.20 GHz |
Error Checking | ECC |
Total Number of Memory Slots | 16 |
Number of Occupied Memory Slots | 1 |
Signal Processing | Registered (Buffered) |
Controllers | |
Controller Type | 12Gb/s SAS |
Controller Model | 930-16i |
RAID Supported | Yes |
RAID Levels | 0, 1, 5, 6, 10, 50, 60, JBOD |
I/O Expansions | |
Number of Total Expansion Bays | 16 |
Number of Internal 2.5" Bays | 16 |
Number of SFF Bays | 16 |
Hot Swappable Bays | Yes |
Display & Graphics | |
Graphics Controller Model | AST2500 |
Graphics Memory Capacity | 512 MB |
Network & Communication | |
Ethernet Technology | Gigabit Ethernet |
Interfaces/Ports | |
Total Number of USB Ports | 4 |
Network (RJ-45) | Yes |
Number of Network (RJ-45) Ports | 1 |
VGA | Yes |
Number of VGA Ports | 2 |
Remote Management | Yes |
Remote Management Controller | Lenovo XClarity |
Operating System | |
Operating System Supported | Windows Server 2019 |
Operating System Supported | SuSE Linux Enterprise Server 15 |
Operating System Supported | SUSE Linux Enterprise Server 12 SP4 |
Operating System Supported | SUSE Linux Enterprise Server 15 SP3 |
Operating System Supported | Red Hat Enterprise Linux 8.8 |
Operating System Supported | Red Hat Enterprise Linux 9.2 |
Operating System Supported | Red Hat Enterprise Linux 9.3 |
Operating System Supported | Ubuntu 24.04 LTS x64 |
Operating System Supported | SUSE Linux Enterprise Server 15 SP2 |
Operating System Supported | Red Hat Enterprise Linux 9.1 |
Operating System Supported | SUSE Linux Enterprise Server 15 SP4 |
Operating System Supported | SUSE Linux Enterprise Server 15 SP6 |
Operating System Supported | Red Hat Enterprise Linux 9.5 |
Operating System Supported | Windows 11 |
Operating System Supported | Red Hat Enterprise Linux 8.5 |
Operating System Supported | Red Hat Enterprise Linux 9.4 |
Operating System Supported | Windows Server 2016 |
Operating System Supported | Red Hat Enterprise Linux 8.3 |
Operating System Supported | Red Hat Enterprise Linux 8.7 |
Operating System Supported | Red Hat Enterprise Linux 9.0 |
Operating System Supported | Ubuntu 22.04 LTS x64 |
Operating System Supported | Windows 10 x64 |
Operating System Supported | Red Hat Enterprise Linux 8.6 |
Operating System Supported | SUSE Linux Enterprise Server 15 SP5 |
Operating System Supported | Red Hat Enterprise Linux 8.4 |
Operating System Supported | SUSE Linux Enterprise Server 12 SP5 |
Operating System Supported | Red Hat Enterprise Linux 8.9 |
Operating System Supported | Red Hat Enterprise Linux 8.10 |
Operating System Supported | Windows Server 2022 |
Power Description | |
Input Voltage | 120 V AC |
Input Voltage | 230 V AC |
Number of Power Supplies Supported | 2 |
Number of Power Supplies Installed | 2 |
Plug/Connector Type | C13 |
Maximum Power Supply Wattage | 1100 W |
Redundant Power Supply | Yes |
Hot Swappable Power Supply | Yes |
Power Source | Power Supply |
Physical Characteristics | |
Form Factor | Rack |
Rack Height | 2U |
Height | 3.4" |
Width | 17.5" |
Depth | 30.1" |
Weight (Approximate) | 78 lb |
Miscellaneous | |
Package Contents |
|
Security Features |
|
Energy Star | Yes |
Energy Efficiency Certification | ENERGY STAR 3.0 |
Warranty | |
Limited Warranty | 3 Year |
Additional Warranty Information | Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD). |
