LENOVO 7Y75A001WW THINKSYSTEM DE4000H FC HYBRID FLASH ARRAY SFF

Lenovo ThinkSystem DE4000H is a scalable, hybrid entry-level storage system that is designed to provide performance, simplicity, capacity, security, and high availability for medium to large businesses. It delivers enterprise-class storage management capabilities with a wide choice of host connectivity options, flexible drive configurations, and enhanced data management features. The ThinkSystem DE4000H is a perfect fit for a wide range of enterprise workloads, including big data and analytics, video surveillance, technical computing, backup and recovery, and other storage I/O-intensive applications.

ThinkSystem DE4000H models are available in a 2U rack form-factor with 24 small form-factor (2.5-inch SFF) drives (2U24 SFF), 12 large form-factor (3.5-inch LFF) drives (2U12 LFF), or a 4U rack form-factor with 60 LFF drives (4U60 LFF) and include two controllers, each with 8 GB cache for a system total of 16 GB. Universal 10 Gb iSCSI or 8/16 Gb Fibre Channel (FC) ports provide base host connectivity, and the host interface cards provide additional 10 Gb iSCSI or 8/16 Gb FC, 12 Gb SAS, 10/25 Gb iSCSI, or 8/16/32 Gb FC connections.

The ThinkSystem DE4000H Storage Array scales up to 192 drives with the attachment of Lenovo ThinkSystem DE120S 2U12, DE240S 2U24 SFF, and DE600S 4U60 LFF Expansion Enclosures. It also offers flexible drive configurations with the choice of 2.5-inch (SFF) and 3.5-inch (LFF) form factors, 10 K rpm SAS and 7.2 K rpm NL SAS hard disk drives (HDDs), and SAS solid-state drives (SSDs).

General Information
Manufacturer	Lenovo Group Limited
Manufacturer Part Number	7Y75A001WW
Manufacturer Website Address	http://www.lenovo.com/us/en/
Brand Name	Lenovo
Product Line	ThinkSystem
Product Series	DE
Product Model	DE4000H
Product Name	ThinkSystem DE4000H iSCSI Hybrid Flash Array SFF
Product Type	SAN Storage System
Storage
Number of Hard Drives Supported	24
Number of Hard Drives Installed	No
Number of Solid State Drive Supported	24
Number of Solid State Drive Installed	No
Network & Communication
Ethernet Technology	10 Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays	24
Number of 2.5" Bays	24
Controllers
Number of Controllers	2
Controller Type	12Gb/s SAS
RAID Supported	Yes
RAID Levels	0, 1, 3, 5, 6, 10
Interfaces/Ports
Number of SAS Ports (External)	4
Total Number of USB Ports	2
Network (RJ-45)	Yes
Management & Protocols
Protocols	LDAP
Protocols	iSCSI
Protocols	SMI-S
Protocols	SSL
Protocols	SNMP
Protocols	SSH
Power Description
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	913 W
Redundant Power Supply	Yes
Physical Characteristics
Height	3.3"
Width	17.7"
Depth	21.8"
Form Factor	Rack-mountable
Rack Height	2U
