APC SMTL1000RMI2UC - UPS - RACK-MOUNTABLE - LINE-INTERACTIVE - 230 V - 800WATT - SER

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 1000VA line interactive 2U short depth rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with IEC 320 C14 input and 6 IEC 320 C13 outlets. This rackmount UPS is tower convertible with the mounting stabilizing feet (SMTL2USF sold separately). It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMTL UPS has a 5-year warranty on the UPS and Lithium-ion battery.

General Information
Manufacturer	Schneider Electric SA
Manufacturer Part Number	SMTL1000RMI2UC
Manufacturer Website Address	http://www.schneider-electric.com
Brand Name	APC by Schneider Electric
Product Line	Smart-UPS
Product Series	SMT
Product Name	Smart-UPS 1000VA Rach-mountable UPS
Product Type	Line-interactive UPS
Technical Information
AVR	Yes
Plug/Connector Type	IEC 60320 C14
Receptacle Type	IEC 60320 C13
Receptacle Type	IEC Jumper
Receptacle Detail	6 x IEC 60320 C13
Number of Battery & Surge Outlets	6
Overload Protection	Yes
Transfer Time	6 ms
Application/Usage	Network Device
Application/Usage	Router
Application/Usage	Network Hub
Application/Usage	POS Terminal
Application/Usage	Rack Server
Application/Usage	Switch
Power Description
Load Capacity (VA)	1000 VA
Load Capacity (Watt)	800 W
Input Voltage	230 V
Input Voltage Range	160 V AC - 280 V AC
Output Voltage	230 V AC
Input Frequency	60 Hz
Output Frequency	60 Hz
Waveform Type	Sine Wave
Surge Energy Rating	680 J
Management
Network Management	SmartConnect
Alarm	On Battery
Alarm	Configurable Delay
Alarm	Low Battery
Controls/Indicators
Status Indicators	LED Status Indicators: Quickly understand unit and power status with visual indicators.
Interfaces/Ports
Serial Port	Yes
Network (RJ-45)	Yes
USB (HID Compliant) Port	Yes
Battery Information
Battery Chemistry	Lithium Ion (Li-Ion)
Backup/Run Time (Full Load)	8 Minute
Backup/Run Time (Half Load)	19 Minute
Typical Battery Recharge Time	3 Hour
Hot Swappable	Yes
Replaceable Battery	Yes
Environmental Conditions
Maximum Operating Temperature	104°F (40°C)
Storage Temperature	14°F (-10°C) - 104°F (40°C)
Maximum Operating Elevation	10000 ft
Maximum Storage Elevation	25000 ft
Storage Relative Humidity	0% - 95%
Sound Emission (A-Weighted)	41 dB(A)
Thermal Dissipation	20.51 W
Physical Characteristics
Color Family	Dual Color
Product Color	Black
Product Color	Silver
Height	3.4"
Width	17.2"
Depth	12.5"
Rack Height	2U
Form Factor	Rack-mountable
Mounting Preference	Lower
Weight (Approximate)	35.94 lb
Miscellaneous
Package Contents	Installation guide Rack Mounting support rails USB cable
Certifications & Standards	C-tick|CE|EAC|RCM|UK PSTI
Product Take Back Program	No
Mercury Free	Yes
RoHS Exemption Information	https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SMTL1000RMI2UC_ROHS_DECLARATION&p_FileName=SMTL1000RMI2UCKIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL	https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=557301634&lang=en-us
EU RoHS Declaration URL	https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=557301634&lang=en-us
Environmental Profile Availability	https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1812001_EN
End of Life Manual Availability	https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1812001_EN
REACH free of SVHC	No
WEEE Statement	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Environmentally Friendly	Yes
Warranty
Limited Warranty	5 Year
Additional Warranty Information	5 year repair or replace
