APC SMTL1000RM2UC SMART-UPS LI-ION SHORT DEPTH 1000VA 120V WITH SMARTCONNECT

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 1000VA line interactive 2U short depth rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA 5-15P input and 6 NEMA 5-15R outlets. This rackmount UPS is tower convertible with the mounting stabilizing feet (SMTL2USF sold separately). It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMTL UPS has a 5-year warranty on the UPS and Lithium-ion battery.

More from the Manufacturer

General Information
Manufacturer	Schneider Electric SA
Manufacturer Part Number	SMTL1000RM2UC
Manufacturer Website Address	http://www.schneider-electric.com
Brand Name	APC by Schneider Electric
Product Line	Smart-UPS
Product Name	Smart-UPS Li-Ion, Short Depth 1000VA, 120V With SmartConnect
Product Type	Line-interactive UPS
Technical Information
Plug/Connector Type	NEMA 5-15P
Receptacle Type	NEMA 5-15P
Receptacle Detail	6 x NEMA 5-15R
Number of Battery & Surge Outlets	6
Cord Length	8 ft
Phase	Single Phase
Application/Usage	Switch
Application/Usage	Server
Application/Usage	POS Terminal
Application/Usage	Network Hub
Application/Usage	Network Device
Application/Usage	Router
Power Description
Load Capacity (VA)	1000 VA
Load Capacity (Watt)	800 W
Input Voltage	120 V AC
Input Voltage Range	82 V AC - 144 V AC
Output Voltage	120 V AC
Input Frequency	60 Hz
Output Frequency	60 Hz
Waveform Type	Sine Wave
Surge Energy Rating	680 J
Management
Alarm	On Battery
Alarm	Low Battery
Alarm	Configurable Delay
Interfaces/Ports
Serial Port	Yes
USB (HID Compliant) Port	Yes
Battery Information
Battery Chemistry	Lithium Ion (Li-Ion)
Typical Battery Recharge Time	3 Hour
Environmental Conditions
Maximum Operating Temperature	104°F (40°C)
Storage Temperature	-40°F (-40°C) - 95°F (35°C)
Maximum Operating Elevation	9842.52 ft
Maximum Storage Elevation	24606.30 ft
Operating Humidity	0% - 95%
Storage Relative Humidity	0% - 95%
Sound Emission	41 dB
Thermal Dissipation	20.51 W
Physical Characteristics
Color Family	Dual Color
Product Color	Black
Product Color	Silver
Height	3.4"
Width	17.2"
Depth	12.5"
Rack Height	2U
Form Factor	Rack-mountable
Mounting Preference	Lower
Weight (Approximate)	36 lb
Miscellaneous
For Country/Region	United States
Package Contents	Smart-UPS Li-Ion, Short Depth 1000VA, 120V With SmartConnect Installation guide Rack mounting support rails USB cable
Certifications & Standards	NOM
Software Included	Powerchute Serial Edition
Optimized Energy Efficiency	Yes
Product Take Back Program	Yes
Mercury Free	Yes
RoHS Exemption Information	https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SMTL1000RM2UC_ROHS_DECLARATION&p_FileName=SMTL1000RM2UCKIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL	https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=511500681&lang=en-us
EU RoHS Declaration URL	https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=511500681&lang=en-us
Environmental Profile Availability	https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1812001EN
End of Life Manual Availability	https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1812001_EN
REACH free of SVHC	No
WEEE Statement	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Country of Origin	Philippines
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Environmental Compliance	Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Environmental Compliance	Battery Directive
Warranty
Limited Warranty	5 Year
Directly Connected Equipment Guarantee	$150000 Lifetime
