BLACK BOX KV2004A 4PORT SERVSWITCH WIZARD DVI DUAL LINK USB
Mfg Part Number: KV2004A , Item #: 1664254
, PO and Wire.
The ServSwitch Wizard™ DVI Dual-Link (USB) 4-Port or 8-Port has breakthrough USB True Emulation technology. This ensures that the full characteristics of the connected USB peripherals-including keyboards and mice-are passed to every system, so specialized features are quickly recognized on the attached devices. What's more, each computer retains this information, even if the device is plugged into another computer. Because of this technology, the switch avoids many of the limitations found in traditional emulations, enabling instantaneous switching and hotkey support.
You can switch up to four or eight PCs via hotkeys, mouse, or RS-232/V.24. The switch provides resolutions up to 2560 x 1600 or 2048 x 2048 at 60 Hz. Plus, it supports duallink DVI-D, single-link DVI-D, and VGA.
Intelligent options port
Flash upgrade the ServSwitch Wizard DVI Dual-Link (USB) via its intelligent options port. You can also switch it via simple RS-232 protocol or even dry contacts. When linked with another ServSwitch Wizard, the options port can be used for synchronous switching of multiple video heads.
USB 2.0 transparency
A clever architecture combines transparent USB 2.0 protocol with emulated keyboard and mouse control. To support this, there are two dedicated keyboard/mouse ports
| General Information | |
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | KV2004A |
| Manufacturer Website Address | http://www.blackbox.com |
| Brand Name | Black Box |
| Product Line | ServSwitch |
| Product Model | KV2004A |
| Product Name | ServSwitch Wizard DVI Dual-Link (USB), 4-Port or 8-Port |
| Product Type | KVM Switchbox |
| Technical Information | |
| Number of Computers Supported | 4 |
| Number of Local Users Supported | 1 |
| Video | |
| Graphic Mode | WQXGA |
| Maximum Video Resolution | 2560 x 1600 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| USB | Yes |
| DVI | Yes |
| Serial Port | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Number of USB Ports | 8 |
| Number of DVI Ports | 5 |
| Power Description | |
| Input Voltage | 110 V AC |
| Input Voltage | 220 V AC |
| Physical Characteristics | |
| Form Factor | Desktop |
| Form Factor | Rack-mountable |
| Height | 1.6" |
| Width | 9.1" |
| Depth | 4.3" |
| Weight (Approximate) | 1.76 lb |
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Country of Origin | United Kingdom |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 2 Year |
