TP LINK
TP LINK S7500-26XF6Y Omada Pro 26-Port 10G Stackable L3 Managed Aggregation Switch with 6 25G Slots
Mfg Part Number: S7500-26XF6Y , Item #: 5475067
Image may not reflect the actual item.
Price: $14,546.18
Quantity:
More to Come
Last Updated: Jun 20, 2025
No Sales Tax except these states
, PO and Wire.
Omada Pro is an intelligent cloud solution for enterprise networking, offering enterprise-grade product line designed to meet the high-capacity, security, and management needs of various industries, such as MDUs, hospitality, K-12 education, public works, and more.
Main Specification
| General Information | |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | S7500-26XF6Y |
| Manufacturer Website Address | http://www.tp-link.com/us |
| Brand Name | TP-Link |
| Product Line | Omada Pro |
| Product Model | S7500-26XF6Y |
| Product Name | Omada Pro 26-Port 10G Stackable L3 Managed Aggregation Switch with 6 25G Slots |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Hot-swappable |
| Features | Surge Protection |
| Features | Loop Protection |
| Features | Secure Boot |
| Interfaces/Ports | |
| Uplink Port | Yes |
| Stack Port | Yes |
| Port/Expansion Slot Details | 6 × 1/10/25 Gigabit Ethernet SFP28 Expansion Slot |
| Port/Expansion Slot Details | 2 × USB 3.0 USB Port |
| Port/Expansion Slot Details | 1 × RJ-45 Console Port |
| Port/Expansion Slot Details | 26 × 1/10 Gigabit Ethernet SFP+Expansion Slot |
| Port/Expansion Slot Details | 1 × RJ-45 Management Port |
| Port/Expansion Slot Details | 1 x USB Type C Console Port |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Ethernet Technology | 25 Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-X |
| Network Technology | 1000Base-X |
| Network Technology | 25GBase-X |
| Maximum Data Transfer Rate | 3.13 GB/s |
| I/O Expansions | |
| Total Number of Expansion Slots | 32 |
| Expansion Slot Type | SFP+ |
| Expansion Slot Type | SFP28 |
| Number of SFP+ Slots | 26 |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.3ad |
| Networking Standards | IEEE 802.1p |
| Networking Standards | IEEE 802.1s |
| Networking Standards | IEEE 802.1x |
| Networking Standards | IEEE 802.3x |
| Networking Standards | IEEE 802.1Q |
| Networking Standards | IEEE 802.1D |
| Networking Standards | IEEE 802.1ab |
| Networking Standards | IEEE 802.1w |
| Management & Protocols | |
| Manageable | Yes |
| Reliability | |
| MTBF | 632865 Hour |
| Power Description | |
| Input Voltage | 120 V AC |
| Input Voltage | 230 V AC |
| Frequency | 50 Hz |
| Frequency | 60 Hz |
| Power Source | AC |
| Power Source | Power Supply |
| Redundant Power Supply Supported | Yes |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 1 |
| Power Consumption | 86.70 W |
| Physical Characteristics | |
| Color Family | Gray |
| Product Color | Gray |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Height | 1.7" |
| Width | 17.3" |
| Depth | 15" |
| Miscellaneous | |
| Application/Usage | Education |
| Application/Usage | Enterprise |
| Application/Usage | Router |
| Application/Usage | Security |
| Application/Usage | Network |
| Application/Usage | Retail |
