The Lenovo ThinkSystem ST550 2-socket 4U rack-mountable tower server provides outstanding performance and industry-leading reliability. It is ideal for small-to-medium businesses, distributed enterprises, retail, educational institutions, and remote/branch offices.
General Information | |
Manufacturer | Lenovo Group Limited |
Manufacturer Part Number | 7X10A0F0NA |
Manufacturer Website Address | http://www.lenovo.com/us/en/ |
Brand Name | Lenovo |
Product Line | ThinkSystem |
Product Series | ST550 |
Product Model | 7X10A0F0NA |
Product Name | ThinkSystem ST550 7X10A0F0NA Server |
Product Type | Server |
Processor | |
Number of Processors Supported | 2 |
Processor Type | Xeon Silver |
Processor Generation | 2nd Gen |
Processor Model | 4208 |
Processor Core | Octa-core (8 Core) |
Processor Speed | 2.10 GHz |
Cache | 11 MB |
Chipset | |
Chipset Manufacturer | Intel |
Chipset Model | C624 |
Memory | |
Standard Memory | 64 GB |
Maximum Memory Supported | 768 GB |
Memory Technology | TruDDR4 |
Memory Clock Speed | 2.93 GHz |
Error Checking | ECC |
Total Number of Memory Slots | 12.0 |
Number of Occupied Memory Slots | 4.0 |
Intel Optane Memory Ready | No |
Signal Processing | Registered (Buffered) |
Controllers | |
Controller Type | Serial ATA |
RAID Supported | Yes |
I/O Expansions | |
PCI Express x8 (Gen 3.x) Slots | 2 |
PCI Express x16 (Gen 3.x) Slots | 5 |
Display & Graphics | |
Graphics Controller Model | G200 |
Graphics Memory Capacity | 16 MB |
Network & Communication | |
Ethernet Technology | Gigabit Ethernet |
Interfaces/Ports | |
Total Number of USB Ports | 9 |
Number of USB 2.0 Ports | 5 |
Number of USB 3.0 Ports | 4.0 |
Network (RJ-45) | Yes |
Number of Network (RJ-45) Ports | 3 |
VGA | Yes |
Number of VGA Ports | 1 |
Remote Management | Yes |
Remote Management Controller | XClarity Controller (XCC) |
Operating System | |
Operating System Supported | Red Hat Enterprise Linux 9.0 |
Operating System Supported | Red Hat Enterprise Linux 8.7 |
Operating System Supported | Red Hat Enterprise Linux 8.3 |
Operating System Supported | Red Hat Enterprise Linux 7.8 |
Operating System Supported | Windows Server 2016 |
Operating System Supported | Red Hat Enterprise Linux 8.5 |
Operating System Supported | SUSE Linux Enterprise Server 15 SP4 |
Operating System Supported | SUSE Linux Enterprise Server 15 SP2 |
Operating System Supported | Red Hat Enterprise Linux 9.1 |
Operating System Supported | Red Hat Enterprise Linux 8 |
Operating System Supported | SUSE Linux Enterprise Server 15 SP3 |
Operating System Supported | SUSE Linux Enterprise Server 15 SP1 |
Operating System Supported | SUSE Linux Enterprise Server 12 SP4 |
Operating System Supported | Red Hat Enterprise Linux 8.2 |
Operating System Supported | Red Hat Enterprise Linux 8.1 |
Operating System Supported | Windows Server 2019 |
Operating System Supported | Windows Server 2022 |
Operating System Supported | SuSE Linux Enterprise Server 15 |
Operating System Supported | SUSE Linux Enterprise Server 12 SP5 |
Operating System Supported | Red Hat Enterprise Linux 8.4 |
Operating System Supported | Red Hat Enterprise Linux 7.6 |
Operating System Supported | Red Hat Enterprise Linux 8.6 |
Operating System Supported | Red Hat Enterprise Linux 7.9 |
Operating System Supported | Ubuntu 22.04 LTS x64 |
Operating System Supported | Red Hat Enterprise Linux 7.7 |
Power Description | |
Input Voltage | 230 V AC |
Input Voltage | 120 V AC |
Number of Power Supplies Supported | 2 |
Plug/Connector Type | C13/C14 |
Power Source | Power Supply |
Physical Characteristics | |
Form Factor | Tower |
Rack Height | 4U |
Height | 17.2" |
Width | 6.9" |
Depth | 26" |
Weight (Approximate) | 79.37 lb |
Miscellaneous | |
Security Features |
|
Energy Star | Yes |
Environmentally Friendly | Yes |
Energy Efficiency Certification | ENERGY STAR 2.1 |
Energy Efficiency Compliance | Energy-related Products Directive Lot 3 (ErP Lot 3) |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Warranty | |
Limited Warranty | 3 Year |
Additional Warranty Information | 3 year customer-replaceable unit and onsite limited warranty. |
