The PT-5T and PT-5R are a twisted pair transmitter and receiver for infrared signals. The units control up to five devices via their own remote control IR transmitters at distances of up to 250m (820ft) over twisted pair cable.

FEATURES

• Multi-Unit IR Control - Controls 2 local and 3 remote devices (DVDs, amplifiers, air conditioners, etc.) over their IR ports.
• Range - Up to 250m (820ft) via twisted pair.
• Flexible Operation - Operates devices that are stacked away in closets, cabinets and other rooms.
• PT-5T - Input: 1 IR receiver on a 3.5mm mini jack; outputs: 2 IR emitters on 3.5mm mini jacks; 1 twisted pair on an RJ-45 connector.
• PT-5R - Input: 1 twisted pair on an RJ-45 connector; outputs: 3 IR emitters on 3.5mm mini jacks.
• Cable - UTP (unshielded twisted pair) or STP (shielded twisted pair) such as CAT 5.
• Sold as a Pair.

The VP-8x8AK is a high-performance matrix switcher for computer graphics video signals, with resolutions up to and exceeding UXGA, and unbalanced stereo audio signals. The unit can route any combination of inputs and outputs and converts the audio to balanced stereo audio outputs.

The TP-205A is a high-performance distribution amplifier for computer graphics video signals with resolutions up to UXGA, RS-232 signals, and stereo or S/PDIF audio signals. The unit takes one set of inputs and outputs five twisted pair signals to compatible receivers.

The PT-101Hxl is a line driver/repeater for HDMI video signals. The unit reclocks and equalizes the signal enabling multiple units to be cascaded.

The VM-24H is a distribution amplifier for HDMI signals. The unit reclocks and equalizes one of two selectable input signals and distributes it to four identical outputs.

• Max. Data Rate - 6.75Gbps (2.25Gbps per graphic channel).

• HDTV Compatible.

• HDCP Compliant.

• HDMI Support - Deep Color, x.v.Color™, Lip Sync, CEC.

• 3D Pass-Through.

• I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling & processing algorithm ensures Plug and Play operation for HDMI systems.

• Active Output LED Indicators.

• Control - Front panel, RS-232, IR switching.

• Worldwide Power Supply - 100-240V AC.

• Standard 19" Rack Mount Size - 1U. Rack "ears" included.

Applications:

• Home theater.
• Presentation and multimedia applications.
• Rental and staging.

Stereo Audio Wall Plate Insert

• Front Panel Connection - 3.5mm (F).
• Rear Panel Connection - 3.5mm (F) on a 12cm (4.7") cable.
• Size - Single slot wall plate insert.

The OC-1N is a high-performance optical isolator for video or sync signals. It provides complete isolation between devices to eliminate video hum, ground loops, and DC offsets that can degrade picture quality.

• Bandwidth - 20MHz (-3dB).
• Channels - 1.
• Opto Isolator Circuitry - Extremely linear response and wide frequency range compared to traditional transformer based units.
• Level (Gain) and EQ (Peaking) Controls.
• Floating Ground Selection - Input, output, both, or none.

Applications

• Large display systems with sources and monitors/projectors on different power circuits.
• Video field production sessions.
• Hospital and other critical applications requiring complete isolation.
• Eliminate Video hum bars and noise.

The MV-6 is a versatile, high-performance multiviewer for 3G HD-SDI video signals. The device can display up to six inputs in any combination and output the image in SDI, HDMI and CV formats. Both pre-programmed and customizable screen divisions are supported. The MV-6-MD is certified for medical applications.

• Max. Data Rate - 3Gbps.
• HDTV Compatible.
• Standards Compliance - Certified for medical applications according to IEC 60601-1-2 (Electromagnetic Compatibility).
• Kramer re-Klocking™ & Equalization Technology - Rebuilds the digital signal to travel longer distances.
• Multi-Standard Operation - SDI (SMPTE 259M), HD-SDI (SMPTE 292M) and 3G HD-SDI (SMPTE 424M).
• Re-Clocking Looping Inputs.
• Multi-Video Output Formats - 3G HD-SDI (SMPTE 424M), HDMI and composite, scaling, refresh rate and video standard conversion.
• Front Panel Preview Screen - 16:9 4.3in color LCD displaying the output of the unit.
• Text Overlay - A text label/icon can be added inside each window. Each label has text/background color, alignment, size, etc settings.
• Screen Handling Buttons - Freeze, size, position, and 4 pre-programmed and 2 user-definable layouts.
• Flexible Control Options - Front panel with 2-row LCD, OSD, Ethernet & RS-232 (supplied with PC control software).
• Worldwide Power Supply - 100-240V AC.

APPLICATIONS

• Professional broadcasting and production studios.
• Presentation applications.

The FC-113 is a high-performance format converter for HDMI signals. It converts an HDMI input signal to two identical SDI video signals with embedded audio. The FC-113-MD is certified for medical applications.

• Max. Data Rate - 3Gbps.
• HDTV Compatible.
• Multi-Standard Operation - SDI (SMPTE 259M), HD-SDI (SMPTE 292M), and 3G HD-SDI (SMPTE 424M).
• Certified for Medical Applications - According to IEC 60601-1-2 (Electromagnetic Compatibility), (FC-113-MD).
• No Frame Rate or Resolution Conversion.
• Active Input™ LED Reporting - Green indicates standard definition (SDI), blue indicates a high-definition (HD-SDI) input signal.

Wall Plate Insert Frame

• USA Version - Holds 6 wall plate inserts.
• International Versions - Hold 4 wall plate inserts.
• Size - Wall Plate - 2 gang European or US.

The TP-102HD is a twisted pair transmitter for computer graphics video and HDTV signals. It converts a computer graphics video or HDTV signal on a 15-pin HD connector to two identical twisted pair signals.

The VP-701xl is a scan converter for computer graphics video signals. The unit converts computer graphics video signals up to 2048x2048 or HDTV signals up to 1080p to two composite and two s-Video (Y/C) signals simultaneously in either PAL or NTSC formats.

The VS-161H is a high-performance switcher for HDMI signals. It reclocks and equalizes the signal and switches one of the 16 inputs to a single HDMI output.

• Max. Data Rate - 4.95Gbps (1.65Gbps per graphic channel).

• HDCP Compliant.

• HDTV Compatible.

• I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling & processing algorithm ensures Plug and Play operation for HDMI systems.

• HDMI Support - With Lip Sync, CEC.

• Dual Mode - PC and DVD Modes selectable by input.

• Flexible Control Options - Front panel, RS-232 (K-Router™ Windows®-based software is included), Ethernet & IR remote (included).

• Video Disconnect.

• Front Panel Lockout.

• Kramer Equalization & re-Klocking™ Technology - Rebuilds the digital signal to travel longer distances.

• Worldwide Power Supply - 100-240V AC.

• Standard 19" Rack Mount Size - 1U. Rack "ears" included.

Applications:

• Ideal for conference room presentations and advertising applications, as well as for rental and staging.
