A mini-tower UPS with line interactive topology, the CyberPower AVR Series CP900AVR provides battery backup (using simulated sine wave output) and surge protection for desktop computers, workstations, networking devices, and home entertainment systems. During longer power outages, the CP900AVR delivers enough battery backup power to perform a graceful shutdown to protect against the loss of data and damage to electronics. It uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The CP900AVR comes with a three-year warranty (including coverage of batteries) and a $300,000 Connected Equipment Guarantee.
General Information | |
Manufacturer | CyberPower Systems, Inc |
Manufacturer Part Number | CP900AVR |
Manufacturer Website Address | https://www.cyberpowersystems.com/ |
Brand Name | CyberPower |
Product Series | AVR UPS |
Product Model | CP900AVR |
Product Name | AVR CP900AVR 900VA UPS |
Product Type | Line-interactive UPS |
Technical Information | |
AVR | Yes |
Plug/Connector Type | NEMA 5-15P |
Receptacle Type | NEMA 5-15R |
Receptacle Detail | 10 x NEMA 5-15R |
Number of Battery & Surge Outlets | 5 |
Number of Surge-only Outlets | 5 |
Dataline Protection | Coax |
Dataline Protection | RJ-45 |
Overload Protection | Yes |
Cord Length | 6 ft |
Transfer Time | 8 ms |
EMI/RFI Noise Filter | Yes |
Energy Saving | GreenPower UPS™ Bypass |
Power Description | |
Load Capacity (VA) | 900 VA |
Load Capacity (Watt) | 560 W |
Input Voltage | 120 V AC |
Input Voltage Range | 88 V AC - 144 V AC |
Output Voltage | 120 V AC |
Waveform Type | Simulated Sine Wave |
Surge Energy Rating | 1500 J |
Circuit Breaker | Yes |
Management | |
Alarm | On Battery |
Alarm | Low Battery |
Alarm | Overload |
Alarm | Fault |
Controls/Indicators | |
Status Indicators |
|
Interfaces/Ports | |
Serial Port | Yes |
USB | Yes |
Battery Information | |
DC System Voltage | 12 V DC |
Number of Batteries | 2 |
Battery Characteristics | Maintenance-free |
Battery Chemistry | Lead Acid |
Backup/Run Time (Full Load) | 5 Minute |
Backup/Run Time (Half Load) | 16 Minute |
Battery Life | 6 Year |
Hot Swappable | Yes |
Typical Battery Recharge Time | 8 Hour |
Replaceable Battery | Yes |
Environmental Conditions | |
Maximum Operating Elevation | 10000 ft |
Maximum Storage Elevation | 50000 ft |
Storage Temperature | 5°F (-15°C) - 113°F (45°C) |
Storage Relative Humidity | 0% - 95% |
Maximum Operating Temperature | 104°F (40°C) |
Physical Characteristics | |
Product Color | Black |
Height | 9.8" |
Width | 3.9" |
Depth | 13.7" |
Form Factor | Mini-tower |
Weight (Approximate) | 21.83 lb |
Miscellaneous | |
Package Contents |
|
Software Included | PowerPanel PE |
Energy Star | Yes |
Environmentally Friendly | Yes |
Country of Origin | Philippines |
Warranty | |
Limited Warranty | 3 Year |
Additional Warranty Information |
|
MODEL- CP900AVR VENDOR- CYBER POWER SYSTEMS, INC.
FEATURES- AVR Series 900AVR UPS
The CyberPower Systems CP900AVR is the ideal unit for mid-level to
upper level computer systems. With battery run times up to 105
minutes, this unit really performs. The CP900AVR not only guards
against surges, spikes, sags, brownouts and other power
abnormalities, but also protects your computer system and valuable
data during a power outage.
The automatic voltage regulation (AVR) will step up low voltages to
safe output levels without resorting to battery power. PowerPanel
Personal Edition Software is included with each model. In the event
of a power outage, PowerPanel Personal Edition Software
automatically saves and closes open files and then shuts down the
computer system in an intelligent and orderly manner.
* Battery run times from 35 to 105 minutes.
* Compact unit with transformer spaced outlets.
* All 8 outlets offer surge protection.
* 1 Transformer spaced outlets.
* Phone/fax/modem/network protection.
* Coax/Cable/DSS protection.
* $300,000 Connected Equipment Warranty.
* PowerPanel Personal Edition software included.
* USB and Serial connectivity
* 3 year warranty
-- SPECIFICATIONS -------------------------------------
VOLT AMP RATING - 900VA
WATTS - 560W
INPUT VOLTAGE - On Utility: 100V - 140V
OUTPUT VOLTAGE - On Battery: 120V + / - 5%
OUTPUT FREQUENCY - On Battery: 60Hz
JOULE RATING - 890 Joules
SURGE CURRENT - 36,000 Amps max.
OVERLOAD PROTECTION- Internal circuitry limiting/Circuit breaker
BATTERY RUN TIME - 35 ~ 105 minutes
OUTLETS - Surge Protected : 4
Battery/Surge Protected: 4
INDICATORS - LEDs for Power on/off, Wiring fault
SOFTWARE - PowerPanel Personal Edition
APPROVALS - UL 1778, cUL, FCC DOC Class B
DIMENSIONS - 3 7/8"w x 9 3/4"h x 13 1/2"d
