70001805 Digi PortServer TS MEI 1 port RS-232/422/485 RJ-45 Serial to Ethernet Device Server, 9-30VDC includes 12V/.5A Wall Mount power supply w/ US plug

Mfg Part Number:  70001805
Image may not reflect the actual item.
Price: $480.01
Quantity:
In Stock: 42
Last Updated: Nov 07, 2025
No Sales Tax except these states
, PO and Wire.
The Digi One TS makes it easy to connect any serial device to your network. It combines the inherent benefits of data networking with proven asynchronous connectivity to deliver powerful, yet simple Ethernet connectivity for all your serial devices.

The Digi One TS delivers universal and powerful features including data security via SSH v2, port buffering, and full SNMP management - making it ideal for applications like console management where device management and monitoring are critical.
Main Specification
General Information
Manufacturer Digi International
Manufacturer Part Number 70001805
Manufacturer Website Address http://www.digi.com
Brand Name Digi
Product Line Digi One
Product Series TS
Product Name One TS Device Server
Product Type Device Server
Interfaces/Ports
Network (RJ-45) Yes
Number of Network (RJ-45) Ports 2
Power Description
Input Voltage 110 V AC
Input Voltage 220 V AC
Input Current 400 mA
Physical Characteristics
Form Factor Desktop
Height 5.4"
Width 3.3"
Depth 0.9"
Weight (Approximate) 2.25 oz
Miscellaneous
Additional Information
  • Easily network-enable virtually any serial device
  • Patented Digi RealPort® Technology for COM or TTY port control and management
  • Switch selectable EIA-232/422/485 for simple interfacing to any type of serial device.
  • Monitoring and diagnostic utility for simple and efficient device monitoring and troubleshooting
  • Data Security via SSH v2
  • Port Buffering for data capture
  • Easy configuration through web interface (HTTP)
  • Industry leading low latency
  • Baud rates up to 230 Kbps
Compatibility Operating systems:
  • AIX
  • HP-UX
  • Linux
  • Microsoft® Windows XP®
  • Microsoft Windows 2000®
  • Microsoft Windows NT®
  • SCO® OpenServer
  • SCO UnixWare
  • Solaris (Intel)
  • Solaris (SPARC)
  • TCP/UDP Socket Services are operating system independent
Certifications & Standards
  • FCC Part 15, A
  • CE
  • EN5024-1
  • EN 50082-1
  • UL 1950
  • CSA 22.2 No 950
  • IEEE 802.3af compliant
Warranty
Limited Warranty 5 Year
product information
Mechanical
Dimensions: WxHxD (mm) 133 x 84 x 24
Mounting Wall Mount
Enclosure Metal
Interface
Serial interface RS232/RS422/RS485
Serial interface number of ports 1
Serial Interface type of connector RJ45
Network interface 1 Port Ethernet RJ45 Connector
Network interface number of ports 1
Network interface type of connector RJ45
Power
Power Input Type Single DC / Jack
Operating Supply Voltage 9 to 30 VDC
Power Consumption 6W
Reliability
Operating Temperature 0 to 55C
Isolation Protection -
Surge Protection Yes
Standards and Certifications FCC Class A, CE Class A, UL, RoHS
The Digi One family of device servers delivers simple, reliable and cost-effective network connectivity for all your serial devices. The Digi One products address the growing need to connect individual devices to the network over industry-standard Ethernet connections in many applications - especially in the building automation, retail/point-of-sale and medical markets. The high-performance Digi One TS allows you to connect serial devices simply and reliably to your Ethernet network. The Digi One TS features selectable EIA-232/422/485 device interfaces, Powered Ethernet (802.3af) support, and an expanded input voltage range of 9-30VDC. It provides 10/100BaseT network interface, DHCP, SNMP, HTTP, PPP, Modbus/TCP.
  • Standard, reliable serial-to-Ethernet connectivity
  • 1, 2 or 4 serial ports
  • Switch selectable RS-232/422/485 RJ-45 serial
Device Type Device server
Width 3.3 in
Depth 5.2 in
Height 0.9 in
Localization North America
Networking
Form Factor External
Connectivity Technology Wired
Data Transfer Rate 230 Kbps
Data Link Protocol Ethernet, Fast Ethernet, RS-232, RS-422, RS-485
Network / Transport Protocol TCP/IP, UDP/IP
Remote Management Protocol SNMP, Telnet, HTTP
Status Indicators Link activity, power
Features DHCP support, RARP support, ARP support
Expansion / Connectivity
Interfaces 1 x network - Ethernet 10Base-T/100Base-TX - RJ-45
1 x serial - RS-232/422/485 - 9 pin D-Sub (DB-9)
Miscellaneous
Compliant Standards CE, FCC Class A certified, CSA, EN50082, UL 1950
Power
Power Device Power adapter - external
Voltage Required AC 120/230 V ( 50/60 Hz )
Software / System Requirements
OS Required SCO OpenServer, UnixWare, IBM AIX, SunSoft Solaris, HP-UX, Microsoft Windows 98 Second Edition, Linux, Microsoft Windows NT, Microsoft Windows 98/ME, Microsoft Windows 2000 / XP
Manufacturer Warranty
Service & Support 5 years warranty
Service & Support Details Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 140 °F
Humidity Range Operating 5 - 90%
