HP B3NT0UT#ABA Z8 G5 TWR 4514Y 64G 1TB

Overview | Supercharge processor-intensive workloads.

Harness the incredible CPU performance of the Z8 AI workstation. With its dual-socket design, accelerate intensive multi-threaded workflows, across AI and machine learning model training, real-time ray tracing, and 3D visualization & simulation, with plenty of room to expand as demands change.

Exceptional performance. Extraordinary expandability.

Tackle processor-intensive workflows with up to 64 cores across 2 Intel® Xeon® W CPUs, 2 high-end GPUs, and 1 TB DDR5 RAM. Easily expand as work evolves with tool-less access, 7 PCIe slots, and 2 front accessible NVMe bays.

Ignite AI innovation.

Accelerate AI development and inferencing with the Z8 AI workstation, with up to 2 NVIDIA RTX™ 6000 Ada Generation GPUs delivering up to 2,914 AI TOPS for advanced AI. Process proprietary data securely on a local workstation to gain insights faster.

Engineered to stay cool and quiet.

Push your desktop workstation without disruptive noise. Smart fan control keeps the system whisper-quiet by tuning fan speeds in real-time using over 20 temperature sensors. Precisely placed vents and ducts streamline airflow and heat removal.

Designed with the planet in mind.

At HP, we care about the impact our products have on our people, communities, and planet. That's why the Z8 contains 40% recycled plastics, 10% recycled metal, 100% sustainably sourced outer box packaging, and is EPEAT® Gold Climate+ registered.

Features | Windows 11

Work anywhere without compromising on performance or security with Windows 11 powered by HP's collaboration and connectivity technology.

Intel® Xeon® processor

Get professional-class speed to maximize your performance and uptimes on the most demanding professional workflows with the Intel® Xeon® processor.

Security is your top priority

The HP Wolf Pro Security Edition provides precon?gured enterprise-level PC protection for small and medium sized businesses.

Professional Grade Graphics

Tackle processor-heavy rendering, machine learning, and data visualization projects.

Ultra Fast Memory Configurations

Power through memory-intensive workloads with fast CPU-dependent rendering, model training and development, and data visualization performance.

General Information
Manufacturer	HP Inc.
Manufacturer Part Number	B3NT0UT#ABA
Manufacturer Website Address	http://www.hp.com
Brand Name	HP
Product Series	Z8 G5
Product Name	Z8 G5 Workstation
Product Type	Workstation
Technical Information
AI-powered	Yes
Processor
Number of Processors Supported	2
Processor Type	Xeon Silver
Processor Model	4514Y
Processor Core	Hexadeca-core (16 Core)
Processor Speed	2 GHz
L3 Cache	30 MB
Processor Socket	Socket LGA-4677
Processor Threads	32
Chipset
Chipset Manufacturer	Intel
Chipset Model	C741
Memory
Standard Memory	64 GB
Maximum Memory Supported	1 TB
Memory Technology	DDR5 SDRAM
Total Number of Memory Slots	16
Error Checking	ECC
Memory Configuration	4 x 16 GB
Signal Processing	Registered
Storage
Drive Type	SSD
Total Solid State Drive Capacity	1 TB
Solid State Drive Interface	PCI Express NVMe 4.0 x4
Controllers
Controller Type	Serial ATA/600
Controller Type	NVMe
RAID Supported	Yes
RAID Levels	0, 1, 5, 10
Display & Graphics
Graphics Controller Model	RTX A1000
Graphics Memory Capacity	8 GB
Graphics Memory Accessibility	Dedicated
Network & Communication
Ethernet Technology	Gigabit Ethernet
Interfaces/Ports
Total Number of USB Ports	14
Number of Onboard USB 2.0 Ports	3
Number of USB 3.1 Gen 1 Ports	10
Number Of Ethernet Ports	2
Optional Ports	Details regarding optional ports aggregated from the information available for this product's family/series. 2 10GbE LAN ports Front I/O: 4 SuperSpeed USB Type-A 5 Gbps signaling rate 1 headphone/microphone combo SD card reader
Input Devices
Keyboard Localization	English
Operating System
Operating System Platform	Windows
Operating System	Windows 11 Pro
Operating System Language	English
Power Description
Input Voltage	120 V AC
Input Voltage	230 V AC
Maximum Power Supply Wattage	1125 W
Frequency	50 Hz
Frequency	60 Hz
Physical Characteristics
Color Family	Black
Product Color	Black
Cooler Type	Air Cooler
Form Factor	Tower
Height	17.5"
Width	8.5"
Depth	21.7"
Weight (Approximate)	49.60 lb
Miscellaneous
Package Contents	Z8 G5 Workstation Keyboard Mouse
Energy Star	Yes
TCO Certified	Yes
Environmentally Friendly	Yes
Environmental Certification	Electronic Product Environmental Assessment Tool Climate+ (EPEAT Climate+)
Environmental Certification	Electronic Product Environmental Assessment Tool Gold (EPEAT Gold)
Energy Efficiency Certification	China Energy Conservation Program (CECP)
Energy Efficiency Compliance	Energy-related Products Directive (ErP)
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Environmental Compliance	Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
Limited Warranty	1 Year
