BLACK BOX

BLACK BOX KVS4-1004KX SECURE KM SWITCHES PROTECT AGAINST CYBER INTRUSION AND MEET THE STRICT REQUIREME

Mfg Part Number:  KVS4-1004KX
Image may not reflect the actual item.
Price: $959.86 + Free Shipping
Quantity:
In Stock: 9
Last Updated: Jun 07, 2026
No Sales Tax except these states
, PO and Wire.

The Black Box Secure KM switches allow a single operator using just one keyboard and mouse to control up to four or eight computers by using the front push buttons saving time, money and space on the desk. Connect the switch to all computers that need to be accessed and all monitors directly to the computers. The switches are ideal for secure command and control applications, government agencies, 911 emergency call centers, and many more. The Secure KM Switches provide peace of mind knowing that each connection is secure. Options include 4-port or 8-port switches with CAC support.

The Secure KM Switches protect your sensitive data using the latest technology. The switches have isolated channels to ensure that data is not leaked between secure ports and the outside world. To prevent eavesdropping attempts through vulnerable devices, the switches support uni-directional data flow from computer to peripheral. Mechanical, electrical, and optical isolation stop hacking and data leaks in environments where security is critical. The Secure KM Switches use protected firmware to keep intruders from re-programming or reading the firmware. Keyboard/internal cache wiping and chassis intrusion protection provide even more security. The Secure KM Switches also use anti-tamper switches and tamper-evident seals to shield your confidential data.

Why Secure KM

Secure KM Switches from Black Box are NIAP PP 4.0 certified and equipped with the highest security features that meet today's Information Assurance safe control standards. The switches contain unique hardware configurations that prevent data leakage between PCs and connected peripherals eliminating potential cyber threats.

Main Specification
General Information
Manufacturer Black Box Corporation
Manufacturer Part Number KVS4-1004KX
Manufacturer Website Address http://www.blackbox.com
Brand Name Black Box
Product Line Secure
Product Model KVS4-1004KX
Product Name KM Switch, NIAP 4.0 Certified - 4-Port, CAC
Packaged Quantity 1
Product Type KM Switchbox
Technical Information
Connectivity Technology Wired
Number of Computers Supported 4
Number of Local Users Supported 1
Device Type Secure KM
Features Intrusion Detection
Features Anti-tamper Switch
Interfaces/Ports
USB Yes
USB Standard USB 2.0
USB 2.0 Yes
Number of USB Ports 11
Environmental Conditions
Minimum Operating Temperature 32°F (0°C)
Maximum Operating Temperature 104°F (40°C)
Power Description
Input Current 3 A
Input Voltage Range 100-240V
Physical Characteristics
Height 1.8"
Width 12.6"
Depth 6.7"
Weight (Approximate) 4.20 lb
Miscellaneous
Package Contents
  • KM Switch, NIAP 4.0 Certified - 4-Port, CAC
  • 1x12 VDC Wallmount Supply (ICP36-120-3000) with US, EU, UK, and AU adapter clips
  • 1x Set of 4 rubber feet (already be attached)
  • 1x Quick Start Guide
Certifications & Standards

NIAP 4.0 Certified

Environmental Compliance Restriction of Hazardous Substances (RoHS)
Country of Origin United States
TAA Compliant Yes
Warranty
Limited Warranty 3 Year
Additional Warranty Information

3 Year Double Diamond™ Warranty (Standard)

WARNING:: The plastic used in cable products can expose you to lead and lead components, chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.P65Warnings.ca.gov
