SRT10KXLI APC Smart-UPS SRT 10000VA 230V

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 10kVA on-line tower UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with hard wire 3-wire(1P+N+E)/5-wire(3P+N+E) input, 6x IEC 320 C13 and 4x IEC 320 C19 outlets, and 3x IEC jumper cables. The UPS has an embedded Network Management Card for UPS network-based monitoring and management. The UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It has an additional SmartSlot for optional accessory card such as Dry Contact I/O card. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. The UPS is compatible with SRTRK2 (4-post) and SRTRK3 (2-post) rail kits sold separately.

General Information
Manufacturer	Schneider Electric SA
Manufacturer Part Number	SRT10KXLI
Manufacturer Website Address	http://www.schneider-electric.com
Brand Name	APC
Product Line	Smart-UPS
Product Series	SRT
Product Name	Smart-UPS SRT 10000VA 230V
Product Type	Double Conversion Online UPS
Technical Information
Receptacle Detail	6 x IEC 60320 C13
Receptacle Detail	1 x Hard Wire 3-wire (H N + E)
Receptacle Detail	4 x IEC 60320 C19
Receptacle Detail	3 x IEC Jumper
Number of Battery & Surge Outlets	25
Protection Type	Spike
Protection Type	Surge
Protection Type	Lightning
Bypass Switch	Internal
Bypass Switch	Automatic & Manual
Emergency Power OFF	Yes
Phase	Single Phase/Three Phase
Power Description
Load Capacity (VA)	10000 VA
Load Capacity (Watt)	10 kW
Input Voltage	415 V AC
Input Voltage	400 V AC
Input Voltage	380 V AC
Input Voltage	230 V AC
Output Voltage	230 V AC
Waveform Type	Sine Wave
Surge Energy Rating	480 J
Circuit Breaker	Yes
Management
Alarm	Battery Failure
Controls/Indicators
Status Indicators	LED Indicators
Interfaces/Ports
Network (RJ-45)	Yes
USB	Yes
Total Number of Expansion Slots	1
Battery Information
Number of Batteries	2
Battery Characteristics	Maintenance-free, Sealed, Spill-proof
Battery Chemistry	Lead Acid
Backup/Run Time (Full Load)	3 Minute
Backup/Run Time (Half Load)	12 Minute
Typical Battery Recharge Time	1.50 Hour
Hot Swappable	Yes
Environmental Conditions
Maximum Operating Temperature	104°F (40°C)
Sound Emission	55 dB
Thermal Dissipation	586.73 W
Physical Characteristics
Color Family	Black
Product Color	Black
Height	17.01"
Width	10.35"
Depth	28.15"
Form Factor	Rack-mountable
Mounting Preference	No Preference
Mounting Location	Front
Weight (Approximate)	246.52 lb
Miscellaneous
For Country/Region	United States
Package Contents	Smart-UPS SRT 10000VA 230V CD with software Documentation CD Installation guide Temperature probe USB cable Warranty card Web/SNMP management card
Certifications & Standards	CE|EAC|IRAM|RCM|VDE
Product Take Back Program	Yes
Mercury Free	Yes
RoHS Exemption Information	https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SRT10KXLI_ROHS_DECLARATION&p_FileName=SRT10KXLIKIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL	https://download.schneider-electric.com/files?p_Doc_Ref=SRT10KXLI_REACH_DECLARATION&p_enDocType=Declaration+of+Conformity+(Sustainability)
EU RoHS Declaration URL	https://download.schneider-electric.com/files?p_Doc_Ref=SRT10KXLI_ROHS_DECLARATION&p_enDocType=Declaration+of+Conformity+(Sustainability)
Environmental Profile Availability	https://download.schneider-electric.com/files?p_Doc_Ref=ENVPEP1512017EN&p_File_name=ENVPEP1512017_EN.pdf
California Proposition 65 Warning	WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Energy Star URL	https://www.energystar.gov/products/data_center_equipment/uninterruptible_power_supplies
REACH free of SVHC	No
Country of Origin	Philippines
SCIP Number	409c68a1-39a6-4e5f-b080-12befe783ad8
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Single-use Plastic (SUP) Free Shipping Packaging	No
Reach Compliance Date	12/10/2025
Sustainable Packaging	No
Packaging Contains Recycled Cardboard	Yes
Warranty
Limited Warranty	3 Year
Additional Warranty Information	UPS: 36 month(s)|Battery: 24 month(s)
