VARIO2 is the next generation of Infra-Red and White-Light illuminators from Raytec. Using the latest PLATINUM Elite SMT LEDs, VARIO2 allows cameras to generate longer illumination distances using less power. VARIO2 features an interchangeable lens system with Hot-spot Reduction Technology to deliver highly even illumination where it is most needed. With the optional hand-held remote control, VARIO2 also makes installation and commissioning quicker, easier and safer. The VARIO2 i2-1 Infra-Red series delivers maximum distances up to 78m (255ft).

The VARIO Universal Bracket (VUB) is a complete family of brackets and mounting plates designed for the custom mounting and configuration of all Raytec VARIO illuminators and PSUs. VUB offers a 'one bracket fits all' approach and provides the easiest and most flexible mounting solution to meet the challenges of any VARIO lighting installation. The VUB bracket system is available in VUB-WALL and VUB-POLE mount variants with a variety of VUB plates available to mount multiple units. VUB accommodates different illuminator and PSU combinations, provides multiple fixing points, and allows independent pan and til0t lighting adjustment.

The RAYMAX series of mains powered Infra-Red illuminators provides class leading performance, long life and requires zero maintenance. They incorporate the very latest surface mount LEDs to deliver outstanding reliability, a highly even light output and excellent surveillance images at night. The unique Adaptive Illumination concept provides the flexibility to alter the angle of illumination on site to match the exact camera field of view. Each unit is fitted with Active LED Life Control to carefully control LED output, delivering consistent illumination power and a projected working life of 10 years. RAYMAX illuminators are supplied with a dedicated power supply as standard. The RAYMAX 300 delivers maximum distances up to 370m (1,214ft).

The VARIO Universal Bracket (VUB) is a complete family of brackets and mounting plates designed for the custom mounting and configuration of all Raytec VARIO illuminators and PSUs. VUB offers a 'one bracket fits all' approach and provides the easiest and most flexible mounting solution to meet the challenges of any VARIO lighting installation. The VUB bracket system is available in VUB-WALL and VUB-POLE mount variants with a variety of VUB plates available to mount multiple units. VUB accommodates different illuminator and PSU combinations, provides multiple fixing points, and allows independent pan and til0t lighting adjustment.

The RAYMAX series of High Performance Infra-Red LED illuminators provide class leading performance, long life and zero maintenance. They incorporate the very latest surface mount LED's to deliver excellent night-time pictures with improved optical output and outstanding reliability.

The unique Adaptive Illumination™ concept provides the flexibility to alter the angle of illumination on site to suit specific security needs and to match the camera's field of view. RAYMAX illuminators are also purpose designed to provide even output illumination.

Each unit is fitted with Active LED Life Control to carefully control LED output, delivering consistent illumination power and a projected working life of 10 years.

RAYMAX illuminators are supplied with bracket and power supply. Control features on the power supply include adjustable power output, photocell and telemetry control. RAYMAX 200 is suitable for all low light installations up to 300 metres (985ft).

The VARIO Universal Bracket (VUB) is a complete family of brackets and mounting plates designed for the custom mounting and configuration of all Raytec VARIO illuminators and PSUs. VUB offers a 'one bracket fits all' approach and provides the easiest and most flexible mounting solution to meet the challenges of any VARIO lighting installation. The VUB bracket system is available in VUB-WALL and VUB-POLE mount variants with a variety of VUB plates available to mount multiple units. VUB accommodates different illuminator and PSU combinations, provides multiple fixing points, and allows independent pan and til0t lighting adjustment.

Delivering world leading power and illumination distances VARIO2 next generation illuminators can improve the performance of any video surveillance system at night.

VARIO2 illuminators use PLATINUM Elite SMT LED technology to deliver more power and greater distances from a smaller platform than current generation illuminators. Providing a broader range of solutions, the VARIO2 series also offers a suite of advanced security features for easier programming and safer operation of smart lighting systems.

VARIO2 features an interchangeable lens system with Hot-spot Reduction Technology to deliver highly even illumination, where it is most needed, for outstanding night-time images. With the optional hand-held remote control, VARIO2 also makes installation and commissioning quicker, easier and safer.

The VARIO2 i6 Infra-Red series delivers maximum distances up to 200m (656ft).

VARIO2 is the next generation of Infra-Red and White-Light illuminators from Raytec. Using the latest PLATINUM Elite SMT LEDs, VARIO2 allows cameras to generate longer illumination distances using less power. VARIO2 features an interchangeable lens system with Hot-spot Reduction Technology to deliver highly even illumination where it is most needed. With the optional hand-held remote control, VARIO2 also makes installation and commissioning quicker, easier and safer. The VARIO2 i4-1 Infra-Red series delivers maximum distances up to 144m (472ft).

The VARIO series of Power Supply Units (PSU) is purpose designed to correctly power all VARIO illuminators including VARIO IP, and provides a platform for the easiest, quickest and safest wiring and installation.

As a full product family, there is a PSU to power any VARIO illuminator. The VARIO PSU requires a 100-230V AC input and provides 24V output. 20W, 50W, 100W and 150W PSU options are available.

With multiple outputs, installers have the ability to power multiple VARIO illuminators from a single PSU (medium, large, and x-large size PSU only). The VARIO PSU also provides CAT5 connectivity for VARIO IP network illuminators (medium, large, and x-large size PSU only).

Each PSU features a 'Fast-Connect' wiring terminal for quick and easy wiring of all VARIO input and output connections, including telemetry input and photocell following output. White-Light LED status indicators are also provided on all fused outputs to indicate the correct voltage and to provide support illumination during wiring.

The VARIO PSU has a high quality IP66 aluminium enclosure making it suitable for all environmental conditions. It also features convenient automotive blade output fuses allowing for fast and easy sourcing and replacement if required. The Slowblow input fuse can also be easily replaced without disconnecting the mains input, for easier and safer installation and maintenance. The VARIO PSU series is suitable for all VARIO low voltage lighting installations.

Features

Powerful

• Powers all VARIO illuminators including VARIO IP
• Powers multiple VARIO illuminators from one PSU

Flexible

• CAT5 connection for VARIO IP (medium, large, and x-large only)
• 'Fast-Connect' easy wiring for all VARIO input and output connections
• Internal illumination for night time installation

Reliable

• High Quality IP66 Aluminium Enclosure
• Automotive blade output fuses - fast and easy sourcing and replacement

Controlled

• Provides correct power for all VARIO illuminators
• Slowblow input fuse - replaceable without disconnecting mains input
• Status indicators signify correct voltage

VARIO2 IP illuminators provide dedicated high-performance lighting for IP cameras. They provide the ultimate solution for smart, situation-dependent lighting for video surveillance and can be fully integrated into an IP eco- system. VARIO2 IP enables users to create dynamic lighting systems, capable of controlling illuminators individually or in groups, to automatically deliver the exact amount of light where and when it is needed, improving image quality under any condition.

Set up is quick and easy, with Raytec's DiscoMan software available as a free download. VARIO2 IP also reduces visits to site, minimising transport and labour costs and saving time, whilst ensuring maximum performance from your system at all times.

VARIO2 IP illuminators feature an interchangeable lens system with Hot-spot Reduction Technology to deliver highly even illumination, where it is most needed, for outstanding night-time images.

With several differently powered variants in the range, VARIO2 IP illuminators are suited to a wide range of applications and deliver maximum distances up to 180m (591ft)

VARIO2 Hybrid illuminators use PLATINUM Elite twin-core SMT LED technology to deliver all the performance of a stand alone Infra-Red and a stand alone White-Light illuminator in a single, fully integrated two-in-one solution.

The Infra-Red illumination can be used for general surveillance whilst the White-Light can be used as a deterrent, or to deliver additional scene information upon activation. Switching from Infra-Red to WhiteLight illumination on-demand is easy, via a volt free switch for external devices or alarm inputs. VARIO2 Hybrid allows the creation of smart lighting systems by using either Infra-Red or White-Light as and when needed.

VARIO2 Hybrid features an interchangeable lens system with Hot-spot Reduction Technology to deliver highly even illumination, where it is most needed, for outstanding night-time images. With the optional hand-held remote control, VARIO2 Hybrid also makes installation and commissioning quicker, easier and safer.

The VARIO2 hy8 series delivers maximum distances up to 290m (951ft) IR & 144m (472ft) WL.

The VARIO2 series of Infra-Red PoE Illuminators is designed to provide dedicated lighting for network cameras. Designed for internal and external applications VARIO2 PoE offers an easy plug-and-play solution for quick lighting integration into an existing network infrastructure. With no PSU required, installation is as simple as plugging in the PoE enabled network cable. Incorporating all standard VARIO family features, including the VARIO interchangeable lens system and hot-spot reduction technology (HRT), VARIO2 PoE i6 illuminators produce outstanding night-time images with maximum distances up to 200m (656ft).
