APC SYH2K6RMT-P1 Symmetra RM 2kVA Scalable to 6kVA with Step-Down Transformer
Mfg Part Number: SYH2K6RMT-P1 , Item #: 94476
Special Note: Jan 05, 2020
NCNR; If you do not have loading facility, please contact our CST for special handling service.
Image may not reflect the actual item.
Price: $4,929.33
+ Free Shipping
Quantity:
In Stock/Mfg Direct Ship
Last Updated: May 03, 2024
No Sales Tax except these states
, PO and Wire.
Symmetra RM 2kVA Scalable to 6kVA N+1 with Step-Down Transformer is high performance, redundant power protection with scalable power and runtime for space-constrained computer rooms and voice and data networks. Symmetra modular design provides redundancy, scalability, manageability and serviceability delivering high availability power protection. Symmetra is ideal for protecting small data centers, network rooms, enterprise IT equipment, PBX, and Industrial applications.
Main Specification
| General Information | |
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SYH2K6RMT-P1 |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Brand Name | APC by Schneider Electric |
| Product Line | Symmetra |
| Product Name | Symmetra RM 2kVA Scalable to 6kVA with Step-Down Transformer |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | NEMA L6-30P |
| Plug/Connector Type | Hard Wire 3-wire |
| Receptacle Type | NEMA L6-30P 30A |
| Receptacle Detail | 12 x NEMA 5-20R |
| Receptacle Detail | 2 x NEMA L6-20R |
| Number of Battery & Surge Outlets | 14 |
| Overload Protection | Yes |
| Cord Length | 10 ft |
| Power Description | |
| Load Capacity (VA) | 2000 VA |
| Input Voltage | 208 V AC |
| Output Voltage | 120 V AC |
| Output Voltage | 208 V AC |
| Input Frequency | 63 Hz |
| Output Frequency | 60 Hz |
| Waveform Type | Sine Wave |
| Management | |
| Network Management | SNMP Manageable |
| Alarm | Low Battery |
| Alarm | Configurable Delay |
| Alarm | On Battery |
| Battery Information | |
| Battery Characteristics | Spill-proof/Maintenance-free |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 11.90 Minute |
| Backup/Run Time (Half Load) | 27.70 Minute |
| Typical Battery Recharge Time | 4 Hour |
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
| Sound Emission (A-Weighted) | 60 dB(A) |
| Physical Characteristics | |
| Product Color | Black |
| Form Factor | Rack-mountable |
| Rack Height | 10U |
| Height | 17.5" |
| Width | 19" |
| Depth | 28.7" |
| Weight (Approximate) | 259.55 lb |
| Miscellaneous | |
| Package Contents | |
| Environmentally Friendly | Yes |
| Environmental Certification | California Proposition 65 |
| Country of Origin | Philippines |
| Warranty | |
| Limited Warranty | 2 Year |
| Additional Warranty Information | 2 years repair or replace, optional on-site warranties available, optional extended warranties available |
The Symmetra RM brings the proven and patented Symmetra Power Array™ technology in a rackmountable form. With more servers, storage products and other mission-critical IT equipment becoming rack-based, the need is increasing for innovative rack based power solutions. Symmetra RM meets this need with 6kVA power increments that can provide N+1 redundancy in just 8U of rack space
Symmetra Rack Mount is an ideal solution for branch office locations, mission-critical networking equipment, or any customer requiring a rack-based product within this power range. In addition to the advantages of hot-swappability and redundancy, rack users can also benefit from Symmetra's self-diagnosing, scaleable components and integrated Web/SNMP management features. The unit can also be used in a floor standing stand alone applications
Symmetra Rack Mount is an ideal solution for branch office locations, mission-critical networking equipment, or any customer requiring a rack-based product within this power range. In addition to the advantages of hot-swappability and redundancy, rack users can also benefit from Symmetra's self-diagnosing, scaleable components and integrated Web/SNMP management features. The unit can also be used in a floor standing stand alone applications
