Image may not reflect the actual item.
Price: $576.85
Quantity:
In Stock: 505
Last Updated: Oct 28, 2025
No Sales Tax except these states
, PO and Wire.
Upgrade your projector setup with the ViewSonic®PA504W high-brightness projector. Featuring a versatile 1.21 - 1.57 throw ratio, this projector can be easily installed onto most existing projector mounts. Plus, with 4,000 ANSI lumens of brightness, audiences can enjoy stunning clarity - even in environments with strong ambient lighting. A Texas instruments .65" DMD chip delivers a high native contrast ratio to make images clearer and more compelling. Each PA504W projector features a sealed optical engine that reduces maintenance as well as state-of-the-art DLP® technology that enables users to enjoy consistent colors and enhanced clarity over an extended period. Connect your projector to Crestron, AMX, PJ Link, ATEN, Extron or other LAN control systems for streamlined device management. Dual HDMI ports enable users to easily switch between content sources. Add an optional ViewSonic WPD-700 Wireless Screen Casting Kit to the projector's USB-A port to make casting content both faster and cable-free.
Main Specification
| General Information | |
| Manufacturer | ViewSonic Corporation |
| Manufacturer Part Number | PA504W |
| Manufacturer Website Address | http://www.viewsonic.com |
| Brand Name | ViewSonic |
| Product Model | PA504W |
| Product Name | 4,000 ANSI Lumens WXGA Education & Business Projector |
| Product Type | DLP Projector |
| Technical Information | |
| Projection Method | Ceiling |
| Projection Method | Front |
| Vertical Scan Range | 23 Hz - 120 Hz |
| Projection Lens | |
| Minimum Focal Length | 16.88 mm |
| Maximum Focal Length | 21.88 mm |
| Minimum Diagonal Image Size | 30" |
| Maximum Diagonal Image Size | 25 ft |
| Optical Zoom | 1.3x |
| Minimum Projection Distance | 30.71" |
| Maximum Projection Distance | 33.27 ft |
| Lamp | |
| Number of Lamps | 1 |
| Lamp Type | UHP |
| Lamp Power | 200 W |
| Normal Mode Lamp Life | 20000 Hour |
| Economy Mode Lamp Life | 30000 Hour |
| Image | |
| Standard Mode Brightness | 4000 lm |
| Color Supported | 1.07 Billion Colors |
| Native Resolution | 1280 x 800 |
| Graphic Mode | WXGA |
| Maximum Resolution | 1920 x 1080 |
| Native Aspect Ratio | 16:10 |
| Throw Ratio | 1.21 to 1.57102.76") |
| Contrast Ratio | 22,000:1 |
| Video | |
| Video Signal Format | PAL |
| Video Signal Format | NTSC |
| Video Signal Format | SECAM |
| Video Signal Standard | HDTV |
| Output Scan Format | 1080p |
| Audio | |
| Speaker Included | Yes |
| Network & Communication | |
| Wireless LAN | Yes |
| Interfaces/Ports | |
| HDMI | Yes |
| USB | Yes |
| Network (RJ-45) | Yes |
| Power Description | |
| Operating Power Consumption | 280 W |
| Physical Characteristics | |
| Product Color | White |
| Color Family | White |
| Form Factor | Ceiling Mountable |
| Form Factor | Wall Mountable |
| Height | 4.3" |
| Width | 11.6" |
| Depth | 8.6" |
| Weight (Approximate) | 5.14 lb |
| Miscellaneous | |
| Application/Usage | Class Room |
| Application/Usage | Education |
| Application/Usage | Presentation |
| Application/Usage | Business |
| Application/Usage | Meeting |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Country of Origin | China |
| TAA Compliant | No |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Three-year limited warranty on parts and labor, 1-year limited warranty on lamp, 1st year free Express Exchange® service** |
