| General Information | |
| Manufacturer | Acer, Inc |
| Manufacturer Part Number | UMWB7AA302 |
| Manufacturer Website Address | http://us.acer.com |
| Brand Name | Acer |
| Product Line | Vero |
| Product Series | B7 |
| Product Model | B227Q E3 |
| Product Name | Vero B227Q E3 Widescreen LED Monitor |
| Product Type | LED Monitor |
| Technical Information | |
| Number of Screens | 1 |
| Screen Size Class | 22" |
| Viewable Screen Size | 21.5" |
| Active Display Area (mm) | 479x260 |
| Screen Mode | Full HD |
| Screen Surface | Anti-glare |
| Panel Technology | In-plane Switching (IPS) Technology |
| Response Time | 4 ms |
| Response Time Details | 4 ms GTG |
| Aspect Ratio | 16:9 |
| Pixel Pitch | 0.24900 mm x 0.24900 mm |
| Horizontal Viewing Angle | 178° |
| Vertical Viewing Angle | 178° |
| Adjustable Display Pivot | Yes |
| Mount Type | Wall Mountable |
| Backlight Technology | LED |
| Maximum Adjustable Height | 5.91" |
| Tilt Angle | -5° to 35° |
| Swivel Angle | -45° to 45° |
| Pivot Angle | +/-90° |
| Horizontal Frequency | 30 kHz to 125 kHz - HDMI |
| Horizontal Frequency | 125 kHz - DisplayPort |
| Horizontal Frequency | 30 kHz to 85 kHz - VGA |
| Vertical Frequency | 48 Hz to 100 Hz - HDMI |
| Vertical Frequency | 48 Hz to 75 Hz - VGA |
| Vertical Frequency | 48 Hz to 100 Hz - DisplayPort |
| Vertical Frequency | 48 Hz to 100 Hz |
| Pivot | Yes |
| Cover Glass | No |
| Video | |
| Maximum Resolution | 1920 x 1080 |
| Maximum Resolution (VGA) | 1920x1080@75Hz |
| Maximum Resolution (DisplayPort) | 1920x1080@100Hz |
| Maximum Resolution (HDMI) | 1920x1080@100Hz |
| Standard Refresh Rate | 100 Hz |
| Color Supported | 16.7 Million Colors |
| Color Depth | 6-bit+FRC |
| Native Contrast Ratio | 1,000:1 |
| Dynamic Contrast Ratio | 100,000,000:1 |
| Brightness | 250 Nit |
| Color Gamut | 99% sRGB |
| Audio | |
| Number of Speakers | 2 |
| Speakers | Yes |
| Speaker Output Power | 2 W |
| Interfaces/Ports | |
| HDMI | Yes |
| HDMI Version | 1.4 |
| VGA | Yes |
| Headphone | Yes |
| DisplayPort | Yes |
| DisplayPort Version | 1.2 |
| Total Number of HDMI Ports | 1 |
| Number of USB 3.2 Ports | 4 |
| Number of USB Type-B Upstream Ports | 1 |
| Number of USB Type-B Downstream Ports | 4 |
| Number of DisplayPorts | 1 |
| Number of VGA Ports | 1 |
| Power Description | |
| Input Voltage Range | 120V to 230V |
| Operating Power Consumption (Energy Star) | 0 mW |
| Standby Power Consumption (Energy Star) | 500 mW |
| Off-Mode Power Consumption (Energy Star) | 300 mW |
| Maximum Power Consumption (Energy Star) | 0 mW |
| Physical Characteristics | |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 100 x 100 |
| Color Family | Black |
| Product Color | Black |
| Height | 11.4" |
| Width | 19.4" |
| Depth | 2.7" |
| Height with Stand | 19.76" |
| Width with Stand | 19.43" |
| Depth with Stand | 8.57" |
| Weight (Approximate) | 5.97 lb |
| Weight with Stand (Approximate) | 11.18 lb |
| Miscellaneous | |
| Package Contents | |
| Energy Star | Yes |
| Country of Origin | China |
| TCO Certified | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | TCO Certified |
