This enterprise class 802.11ax ruggedized indoor/outdoor/industrial AP provides three radios and four spacial streams. As a top-of-the-line Wi-Fi 6 access point it provides OFDMA, a 2.5 Gigabit Ethernet port, plus an additional 1 Gbps Ethernet port with PoE out. The AP can provide 24/7 scanning across both bands while still providing access on both the 2.4 GHz and 5 GHz bands. The integrated BLE radio can be used for beacons and locationing applications.
FAP-432FR is ideal for hazardous environments such as oil rigs, industrial manufacturing, and transportation sites.
General Information | |
Manufacturer | Fortinet, Inc |
Manufacturer Part Number | FAP432FRE |
Manufacturer Website Address | http://www.fortinet.com |
Brand Name | Fortinet |
Product Line | FortiAP |
Product Model | 432FR |
Product Name | FortiAP 432FR Wireless Access Point |
Product Type | Wireless Access Point |
Technical Information | |
Wireless LAN Standard | IEEE 802.11a/b/g/n/ac/ax/d/h/i/k/r/v/w/u/e/j |
Network Band | Dual Band |
Frequency Band | 5 GHz |
Frequency Band | 2.40 GHz |
Total Number of Antennas | 6 |
Number of External Antennas | 6 |
Indoor/Outdoor | Indoor/Outdoor |
Wireless Transmission Speed | 3.47 Gbit/s |
MIMO Technology | Yes |
Data Encryption | Yes |
Encryption Standard | WPA |
Encryption Standard | WPA3 |
Encryption Standard | WPA3-PSK |
Encryption Standard | WEP |
Encryption Standard | WPA2 |
Ingress Protection (IP) Rating | IP67 |
Interfaces/Ports | |
Ethernet Technology | Gigabit Ethernet |
Ethernet Technology | 2.5 Gigabit Ethernet |
Number of Network (RJ-45) Ports | 2 |
PoE (RJ-45) Port | Yes |
PoE PD Port | Yes |
USB | Yes |
Management Port | Yes |
Network & Communication | |
Wi-Fi Generation | Wi-Fi 6 |
Power Description | |
Power Consumption | 25 W |
Physical Characteristics | |
Form Factor | Desktop |
Form Factor | Pole-mountable |
Form Factor | Wall Mountable |
Antenna Form Factor | External |
Height | 2.4" |
Width | 8.2" |
Depth | 8.2" |
Weight (Approximate) | 5.12 lb |
Miscellaneous | |
Package Contents |
|
Environmentally Friendly | Yes |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Warranty | |
Limited Warranty | Lifetime |
