Evolve your Mini PC Experience
The Topaz 3 NUC harnesses Intel's latest 13th Gen Raptor Lake 1340P Processor with Iris Xe graphics to provide the most crisp computing experience to date. With up to 64GB of DDR4- 3200 memory and up to 10TB of M.2 storage, Topaz 3 has the capabilities you need to evolve your mini PC experience or corporate infrastructure to the latest and greatest technology available. Intel's 13th Gen 1340P processor ushers a host of new and improved features including increased core counts and an upgraded Intel® Thread Director to increase both your efficiency and your productivity.
Crystal Clear, Clean & Secure Computing
From a home theater to a digital signage kiosk, the Intel® Iris Xe Graphics in Topaz 3 have you covered. With support for up to four 4K displays, you can enjoy crisp visuals from every angle. Take advantage of super-fast networking with dual 2.5Gb LAN ports and onboard TPM 2.0, giving you a robust and secure connection to your home or office network, or ditch the cabling and go wireless with Wi-Fi 6E and Bluetooth 5.3 for that sleek setup look, without sacrificing performance and reliability.
The Number One Choice for your Next Mini PC
Topaz 3 offers a plethora of customization options while maintaining that 4x4 footprint people love. From Gen4 PCIe drives, to I/O options like additional USB ports and serial adapters via the replaceable lid, you have the versatility you need to meet your use case. The Topaz 3 NUC with a 13th Gen Intel® Core 1340P Processor is the number one choice for your mini PC needs for both the home and the office, so get yours, today.
| General Information | |
| Manufacturer | SimplyNUC |
| Manufacturer Part Number | 91M-BHG5-0C1 |
| Manufacturer Website Address | http://www.simplynuc.co.uk |
| Brand Name | SimplyNUC |
| Product Line | Topaz 3 |
| Product Model | NUC13TZi5 |
| Product Name | Topaz 3 NUC13TZi5 Desktop Computer |
| Product Type | Desktop Computer |
| Processor | |
| Processor Manufacturer | Intel |
| Processor Type | Core i5 |
| Processor Generation | 13th Gen |
| Processor Model | i5-1340P |
| Processor Core | Dodeca-core (12 Core) |
| Maximum Turbo Speed | 4.60 GHz |
| Chipset | |
| Chipset Manufacturer | Intel |
| Memory | |
| Standard Memory | 16 GB |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR4 SDRAM |
| Total Number of Memory Slots | 2.0 |
| Storage | |
| Total Solid State Drive Capacity | 512 GB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| SSD Form Factor | M.2 |
| Display & Graphics | |
| Graphics Controller Manufacturer | Intel |
| Graphics Controller Model | Iris Xe Graphics |
| Graphics Memory Technology | DDR4 SDRAM |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| LAN Model | i225-LM |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Bluetooth | Yes |
| Interfaces/Ports | |
| HDMI (Rear) | Yes |
| Total Number of USB Ports | 6 |
| Number of USB 3.2 Gen 2 Ports | 4 |
| USB Type-C (Front) | Yes |
| USB Type-C Detail | 2x USB 3.2 Gen2 Type-C |
| Number Of Ethernet Ports | 2 |
| Number of DisplayPort Outputs (Rear) | 1 |
| DisplayPort (Rear) | Yes |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Power Description | |
| Maximum Power Supply Wattage | 90 W |
| Physical Characteristics | |
| Form Factor | Mini PC |
| Height | 1.9" |
| Width | 4.5" |
| Depth | 4.5" |
| Miscellaneous | |
| Package Contents |
|
| Features | Security Slot |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3-yr Warranty and Support Service |
