HANWHA TECHWIN
HANWHA TECHWIN XNB-8002 WISENET 7 X SERIES NETWORK BOX CAMERA, 6
Mfg Part Number: XNB-8002 , Item #: 4209781
Image may not reflect the actual item.
Price: $761.17
+ Free Shipping
Quantity:
More to Come
Last Updated: Oct 24, 2025
No Sales Tax except these states
, PO and Wire.
Wisenet X powered by Wisenet 7 network box camera, easy access to all ports, 6MP @30fps, H.265/H.264/MJPEG, WiseStream II compression technology, extremeWDR, USB port for easy installation, advanced video analytics and sound classification, true D/N, dual SD card slots, hallway view, HLC, defocus detection, defog detection, DIS, 12VDC/24VAC/PoE. Advanced cybersecurity built-in.
Main Specification
| General Information | |
| Manufacturer | Hanwha Group |
| Manufacturer Part Number | XNB8002 |
| Manufacturer Website Address | http://www.hanwha.com |
| Brand Name | Wisenet |
| Product Series | X |
| Product Model | XNB-8002 |
| Product Name | 6MP Network Box Camera |
| Product Type | Network Camera |
| Technical Information | |
| Recording Formats | HD |
| HD Recording | Yes |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Color Supported | Monochrome |
| Color Supported | Color |
| Field of View | H: 114°(Wide)~40.2°(Tele) V: 62.0°(Wide)~22.5°(Tele) D: 133.0°(Wide)~46.3°(Tele) |
| Effective Camera Resolution | 6 Megapixel |
| Video | |
| Video Formats | H.265 |
| Video Formats | H.264 |
| Video Formats | MJPEG |
| Maximum Video Resolution | 3328 x 1872 |
| Maximum Frame Rate | 30 fps |
| Lens | |
| Lens Type | Varifocal |
| Minimum Focal Length | 2.80 mm |
| Maximum Focal Length | 8.40 mm |
| Lens Mount Type | CS-Mount |
| Optical Zoom | 3x |
| Exposure | |
| Shortest Shutter Speed | 1/12000 Second |
| Longest Shutter Speed | 1/5 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Input Voltage | 12 V DC |
| Input Voltage | 24 V AC |
| Physical Characteristics | |
| Mount Type | Bracket Mount |
| Form Factor | Box |
| Color Family | Black |
| Product Color | Black |
| Height | 2.6" |
| Width | 3.2" |
| Depth | 6.5" |
| Weight (Approximate) | 1.94 lb |
| Environmental Conditions | |
| Minimum Operating Temperature | 14°F (-10°C) |
| Maximum Operating Temperature | 131°F (55°C) |
| Maximum Operating Humidity | 90% |
| Miscellaneous | |
| Features | Privacy Masking |
| Features | Back Light Compensation (BLC) |
| Features | Gain Control |
| Features | Defog |
| Features | White Balance |
| Features | Motion Detection |
| Features | Digital Image Stabilization |
| Features | Wide Dynamic Range |
| Features | Day/Night |
| Features | Digital Noise Reduction |
| Indoor/Outdoor | Indoor/Outdoor |
| NDAA Compliant | Yes |
