IOLAN SCS Console Servers enable administrators to securely access remote serial console ports on equipment such as PBX, servers, routers, network storage equipment and security appliances through an IP network. Data management information is protected through standard encryption tools such as Secure Shell (SSH) and Secure Sockets Layer (SSL). Access by authorized users is assured via authentication schemes such as RADIUS, TACACS+, LDAP, Kerberos, NIS and RSA Security's SecurID tokens.
By using encryption technologies, an IOLAN Console Server protects sensitive and confidential data before being sent across a corporate Intranet or public Internet. For compatibility with peer encryption devices, all of the major encryption ciphers such as AES, 3DES, RC4, RC2 and CAST128 are fully supported.
Recognized as the most secure method for communicating to remote private networks over the Internet, the IPSec standard provides robust authentication and encryption of IP packets at the network layer of the OSI model. As a standard it is ideal for multi-vendor interoperation within a network, providing flexibility and the ability to match the right solution for a particular application.
High Availability AccessThe IOLAN SCS has built-in fault tolerant capabilities to ensure secure and reliable access for managing important mission critical equipment. Dual Ethernet interfaces on the IOLAN SCS provide redundant network paths while dual AC power supply models ensure that console management is available even if the primary AC power source fails. For remote administrators that require access from home, on the road or in the event of a total network failure, an optional IOLAN V.92 modem card delivers a solid, integrated solution with direct phone line attachment via its onboard RJ11 jack.
Protection against electrostatic discharges and power surges is provided with robust 15Kv ESD protection circuitry on each serial port.
General Information | |
Manufacturer | Perle Systems, Inc |
Manufacturer Part Number | 04030224 |
Manufacturer Website Address | http://www.perle.com |
Brand Name | Perle |
Product Line | IOLAN |
Product Series | SCS |
Product Model | SCS8 |
Product Name | IOLAN SCS Console Server |
Product Type | Device Server |
Processor & Chipset | |
Processor Speed | 400 MHz |
Memory | |
Standard Memory | 64 MB |
Media & Performance | |
Media Type Supported | Twisted Pair |
Network & Communication | |
Ethernet Technology | Gigabit Ethernet |
Network Standard | 10/100/1000Base-T |
Interfaces/Ports | |
Network (RJ-45) | Yes |
Phone Line (RJ-11) | No |
Network (RJ-11) | No |
USB | No |
Serial Port | Yes |
Parallel Port | No |
Centronics Port | No |
Management Port | Yes |
PoE (RJ-45) Port | No |
Number of Network (RJ-45) Ports | 2 |
Number of Serial Ports | 8 |
Power Description | |
Input Voltage | 240 V AC |
Physical Characteristics | |
Form Factor | Rack-mountable |
Height | 1.8" |
Width | 17.1" |
Depth | 10.4" |
Weight (Approximate) | 6.61 lb |
Miscellaneous | |
Package Contents |
|
Country of Origin | Canada |
Warranty | |
Limited Warranty | Lifetime |
Additional Warranty Information | The Perle IOLAN SCS8 is backed by the best service and support in the industry including Perle's unique lifetime warranty. Since 1976 Perle has been providing its customers with networking products that have the highest levels of performance, flexibility and quality. |
Mechanical | |
Dimensions: WxHxD (mm) | 264 x 434 x 44 |
Mounting | Rack Mount |
Enclosure | Metal |
Interface | |
Serial interface | RS232 |
Serial interface number of ports | 8 |
Serial Interface type of connector | RJ45 |
Network interface | 2 Port Gigabit Connector |
Network interface number of ports | 2 |
Network interface type of connector | RJ45 |
Power | |
Power Input Type | - |
Operating Supply Voltage | 48 VDC |
Power Consumption | 18W |
Reliability | |
Operating Temperature | 0 to 55C |
Isolation Protection | Yes |
Surge Protection | - |
Standards and Certifications | Safety UL 60950-1, EN 60950-1, EMC CE, FCC, EMI EN 55022 Class A, FCC Part 15 Subpart B Class A, EMS EN 55024 |
General Information | |
Marketing Information | The IOLAN SCS is the most advanced series of multi-port console serversavailable. Delivering the highest level of reliability and performance in a1U form factor, an IOLAN SCS offers robust security, flexibility and nextgeneration IP technology, ideal for managing remote equipment via theirserial console ports. Available in 8, 16 and 32 port sizes, the IOLAN SCSseries has the right fit for your serial application needs. |
Technical Information | |
Functions | IOLAN SCS console servers enable administrators to securely access remoteserial console ports on equipment such as PBX, servers, routers, network storage equipment and security appliances through an IP network. The IOLAN SCS has built-in fault tolerant capabilities to ensure secure and reliable access for managing important mission critical equipment. |
Management & Protocols | |
Management | Web browser or secure web browser via https(SSL/TLS ), Perle DeviceManager software to managesingle or multiple device servers, IOLAN+ Configuration mode, Event notification via email, CLI -Telnet, SSH, shared console portSNMP, MIB II, Perle MIB, read and writeCapabilities,SYSLOG,Port Buffering-local or 3DES encrypted toNFS server |
Security | SSHV1 and SSHV2,SSL V3.0/TLS V1.0, SSL V2.0,SSL Server and SSL client mode capability,Encryption: AES (256/192/128), 3DES,DES, Blowfish, CAST128, ARCFOUR(RC4), ARCTWO(RC2),Hashing Algorithms: MD5, SHA-1,RIPEMD160, SHA1-96, and MD5-96,Key exchange: RSA, EDH-RSA, EDH-DSS, ADH, X.509 Certificate verification: RSA, DSA,Certificate authority (CA) list, |
Controls/Indicators | |
Status Indicators | Power/Ready,System Ready,Network Link activitySerial : Tx and Rx data LEDs |
Miscellaneous | |
Package Contents | CD,Quick Start Guide, RJ-45 TO DB9M Adapter, Rack mounting brackets included |
Certifications & Standards | FCC Part 15A, CE, CAN/CSA 22.2, UL60950, EN 55022 Class A, EN 55024 Class A |
Warranty | |
Additional Warranty Information | The Perle IOLAN SCS8 is backed by the best service and support in the industryincluding Perle's unique lifetime warranty. Since 1976 Perle has been providing itscustomers with networking products that have the highest levels of performance,flexibility and quality. |
