SUPERMICRO

SUPERMICRO SYS-2049P-TN8R NR X11QPL CSE-218LTS-R2K21P 2 U 4-WAY CLOUD OPTIMIZED

Mfg Part Number:  SYS-2049P-TN8R
Image may not reflect the actual item.
Price: $6,655.92 + Free Shipping
Quantity:
In Stock/Mfg Direct Ship
Last Updated: Dec 04, 2025
No Sales Tax except these states
, PO and Wire.

Supermicro introduces its latest generation 2U rackmount 4-Way MP server. The MP line of SuperServers are designed to deliver the highest performance, Resource-Savings, flexibility, scalability and serviceability to power mission-critical Enterprise workloads like ERP, large in-memory databases, and real time analytics by scaling up to the maximum processing and memory afforded in one node.

Main Specification
General Information
Manufacturer Supermicro Computer, Inc
Manufacturer Part Number SYS-2049P-TN8R
Manufacturer Website Address http://www.supermicro.com
Brand Name Supermicro
Product Line SuperServer
Product Model 2049P-TN8R
Product Name SuperServer 2049P-TN8R (Black)
Product Type Server Barebone System
Processor
Number of Nodes 1
Number of Processors Supported 4
Processor Socket Socket P LGA-3647
Processor Supported Xeon Platinum
Processor Supported Xeon Silver
Processor Supported Xeon Bronze
Processor Supported Xeon Gold
64-bit Processing Yes
Chipset
Chipset Manufacturer Intel
Chipset Model C621
Memory
Maximum Memory Supported 12 TB
Memory Technology DDR4 SDRAM
Memory Standard DDR4-2933/PC4-23466
Total Number of Memory Slots 48
Intel Optane Memory Ready Yes
Controllers
Controller Type Serial ATA/600
RAID Supported Yes
Display & Graphics
Graphics Controller Model AST2500
Network & Communication
Ethernet Technology Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays 10
Total Number of Expansion Slots 7
Number of PCI Express x8 Slots 5
Number of PCI Express x16 Slots 2
Interfaces/Ports
Total Number of USB Ports 2
Number of USB 3.0 Ports 2
Number of SATA Interfaces 2
Power Description
Input Voltage 120 V AC
Input Voltage 230 V AC
Number of Power Supplies Installed 2
Maximum Power Supply Wattage 2200 W
Physical Characteristics
Color Family Black
Product Color Black
Form Factor Rack-mountable
Rack Height 2U
Height 3.5"
Width 17.2"
Depth 30.2"
Weight (Approximate) 47.50 lb
Miscellaneous
Package Contents
  • SuperServer 2049P-TN8R (Black)
  • 1 x Super X11QPL Motherboard
  • 1 x 2U Chassis
  • 1 x 2U Backplane Supports 8 x 2.5" NVMe and 2 x 2.5" SAS3/SATA3 Storage Media,HF,RoHS
  • 1 x MINI SAS-4 SATA,INT,51CM,51CM SB,30AWG
  • 1 x PWEX,2X4F/P4.2 TO 2X2F/P4.2 x2,BLK*4,YEL*4,30CM,18AWG
  • 1 x SLIMLINE SAS (LE) to SLIMLINE SAS, INT, 57CM,32AWG,85
  • 1 x SLIMLINE SAS (LE) to SLIMLINE SAS, INT, 62CM,32AWG,85
  • 1 x SLIMLINE SAS (LE) to SLIMLINE SAS, INT, 39CM,32AWG,85
  • 1 x SLIMLINE SAS x8 to SLIMLINE SAS x8, INT, 10CM,32AWG,85
  • 4 x 2U Passive CPU Heat Sink for X11 Purley Platform Equipped with a Narrow Retention Mechanism
  • 2 x 2U 2200W power supply with PMBus and 200-240Vdc input,RoHS
  • 2 x 80x80x38 mm, 14.9K RPM for SC218L Low Cost 4-way Server
Environmentally Friendly Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty 3 Year
