HANWHA TECHWIN
HANWHA TECHWIN XNV-6022R Wisenet X powered by Wisenet 5 network outdoor vandal dome camera 2MP Full HD(1080p) @60fps 3.6mm fixed lens (94.8 ) triple codec H.265/H.264/MJPEG with WiseStream II technology
Mfg Part Number: XNV-6022R , Item #: 3092752
Image may not reflect the actual item.
Price: $612.36
+ Free Shipping
Quantity:
More to Come
Last Updated: Mar 14, 2026
No Sales Tax except these states
, PO and Wire.
Wisenet X powered by Wisenet 5 network outdoor vandal dome camera, 2MP, Full HD(1080p) @60fps, 3.6mm fixed lens (94.8°), triple codec H.265/H.264/MJPEG with WiseStream II technology, 150dB WDR, USB port for easy installation, advanced video analytics and sound classification, IR LEDs range of 49', true D/N, single SD card, hallway view, HLC, defog detection, DIS, PoE, IP66, IK10 NEMA 4X
Main Specification
| General Information | |
| Manufacturer | Hanwha Group |
| Manufacturer Part Number | XNV-6022R |
| Manufacturer Website Address | http://www.hanwha.com |
| Brand Name | Wisenet |
| Product Series | X |
| Product Model | XNV-6022R |
| Product Name | 2MP Mobile Vandal Dome |
| Product Type | Network Camera |
| Technical Information | |
| Recording Formats | Full HD |
| HD Recording | Yes |
| Night Vision | Yes |
| Night Vision Distance | 49.21 ft |
| Night Vision Type | Infrared |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Color Supported | Monochrome |
| Color Supported | Color |
| Field of View | H : 94.8° / V : 49.3° / D : 114.3° |
| Effective Camera Resolution | 2 Megapixel |
| Video | |
| Video Formats | MJPEG |
| Video Formats | MPEG-4 AVC |
| Video Formats | H.264 |
| Video Formats | H.265 |
| Maximum Video Resolution | 1920 x 1080 |
| Maximum Frame Rate | 60 fps |
| Lens | |
| Lens Type | Fixed |
| Maximum Focal Length | 3.60 mm |
| Lens Included | Yes |
| Lens Mount Type | Board Mount |
| Maximum Aperture | f/2 |
| Exposure | |
| Shortest Shutter Speed | 1/12000 Second |
| Longest Shutter Speed | 2 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Input Voltage | 2.5 V DC |
| Physical Characteristics | |
| Mount Type | Pole Mount |
| Form Factor | Dome |
| Durability | Vandal Resistant |
| Color Family | White |
| Product Color | Ivory |
| Height | 2" |
| Width | 3.9" |
| Depth | 3.9" |
| Weight (Approximate) | 10.41 oz |
| Environmental Conditions | |
| Minimum Operating Temperature | -22°F (-30°C) |
| Maximum Operating Temperature | 131°F (55°C) |
| Maximum Operating Humidity | 90% |
| Miscellaneous | |
| Features | Audio Compression |
| Features | Gain Control |
| Features | SD Card Local Storage |
| Features | Digital Noise Reduction |
| Features | Privacy Masking |
| Features | White Balance |
| Features | Auto Tracking |
| Features | Digital Image Stabilization |
| Features | Defog |
| Features | Motion Detection |
| Indoor/Outdoor | Outdoor |
| NDAA Compliant | Yes |
