, PO and Wire.
Features DB25 to DB25 link cable (2 m)
Note Select C32050T for longer distances
| Power Requirements | |
| Power Consumption | C32010T/PCI: 500 mA max. @ +5 V C32010T: 840 mA max. @ +5 V |
| Power Consumption | 710 mA max. @ +5 V |
| Serial Communication Parameters | |
| Data Bits | 5, 6, 7, 8 |
| Data Bits | 5, 6, 7, 8 |
| Parity | None, Even, Odd, Space, Mark |
| Parity | None, Even, Odd, Space, Mark |
| Stop Bits | 1, 1.5, 2 |
| Stop Bits | 1, 1.5, 2 |
| IRQ | C32010T/PCI: Assigned by BIOS C32010T: 2 (9), 3, 4, 5, 7, 10 (default), 11, 12, 15 |
| IRQ | Assigned by BIOS |
| Hardware | |
| Processor | TMS320BC52-40 RISC CPU |
| Processor | TI DSP TMS320BC52PJ |
| Connector | DB25 female |
| Connector | DB25 female |
| Bus | PCI Express x 1 |
| Bus | C320Turbo/PCI: 32-bit Universal PCI C320Turbo: 16-bit ISA |
| Comm. Controller | 16C550C or compatible x 8 |
| Comm. Controller | 16C550C or compatible x 8 |
| Memory | 512 KB |
| Memory | 512 KB |
| Performance | |
| Baudrate | 50 bps to 460.8 Kbps |
| Baudrate | 50 bps to 460.8 Kbps |
| Environmental Limits | |
| Operating Temperature | 0 to 55°C (32 to 131°F) |
| Operating Temperature | 0 to 55°C (32 to 131°F) |
| Storage Temperature | -20 to 55°C (-4 to 131°F) |
| Storage Temperature | -20 to 85°C (-4 to 185°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| MTBF (mean time between failures) | |
| Time | 305,270 hrs |
| Database | MIL-HDBK-217F, GB 25°C |
| Physical Characteristics | |
| Dimensions | 135 x 67 mm (5.32 x 2.64 in) |
| Dimensions | C32010T/PCI: 90 x 120 mm (3.54 x 4.72 in) C32010T: 107 x 158 mm (4.21 x 6.22 in) |
| Serial Interface | |
| Serial Standards | RS-232 (RS-422 available with desktop option) |
| Serial Standards | RS-232 (RS-422 available with desktop option) |
| Number of Ports | 32 per control board (max.) |
| Number of Ports | 32 per control board (max.) |
| Max. No. of Boards per PC | 4 |
| Max. No. of Boards per PC | 4 |
| Serial Signals | |
| RS-422 | TxD+/-, RxD+/-, RTS+/-, CTS+/-, GND |
| RS-422 | TxD+/-, RxD+/-, RTS+/-, CTS+/-, GND |
| RS-232 | TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND |
| RS-232 | TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND |
| Standards and Certifications | |
| EMI | EN 55022, FCC Part 15 Subpart B Class A |
| EMI | EN 55022, FCC Part 15 Subpart B Class A |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4 |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4 |
| EMC | CE, FCC |
| EMC | CE, FCC |
| Green Product | RoHS, CRoHS, WEEE |
| Green Product | RoHS, CRoHS, WEEE |
| Driver Support | |
| Operating Systems | Windows 9X/ME/NT/2000, Windows XP/2003/Vista/2008/7 x86/x64, DOS, Linux 2.4, Linux 2.6 x86/x64, SCO Open Server 5/6, UnixWare 7, QNX 4/6 |
| Operating Systems | Windows 2000, Windows XP/2003/Vista/2008/7 x86/x64, Linux 2.4, Linux 2.6 x86/x64 |
| Note | Please refer to Moxa's website for the latest driver support information. |
| Note | Please refer to Moxa's website for the latest driver support information. |
| Warranty | |
| Warranty Period | 5 years |
| Warranty Period | 5 years |
| Details | See www.moxa.com/warranty |
| Details | See http://www.moxa.com/support/warranty.htm |
