4XEM 4XHDMI164K2K 16PORT HDMI VIDEO SPLITTER 4K 1080P 4KX2K 1920X1080 2YR WARRANTY

Mfg Part Number:  4XHDMI164K2K
Image may not reflect the actual item.
Price: $172.86 + Free Shipping
Quantity:
More to Come
Last Updated: Dec 17, 2025
No Sales Tax except these states
, PO and Wire.

4XEM 16-Port HDMI Splitter and Signal Amplifier for 4K/2K 3D

Split the UHD 3D 4K/2K signal from one HDMI device into sixteen using 4XEM's 1x4163D 4K/2K HDMI splitter (4XHDMI164K2K). Simply connect your 3D or 4K/2K Displays to the splitter's outputs.

Problem it solves: Display your video on multiple HDMI compatible televisions or monitors. Ideal for retail displays, trade shows, sports bar, etc.

4XEM gear is respected industry wide for its high performance, premium quality and our after sales support.

More from the Manufacturer

Main Specification
General Information
Manufacturer 4XEM Corporation
Manufacturer Part Number 4XHDMI164K2K
Manufacturer Website Address http://www.4xem.com
Brand Name 4XEM
Product Model 4XHDMI164K2K
Product Name 16 Port HDMI 4K Splitter
Product Type Signal Splitter
Technical Information
Maximum Frequency 340 MHz
Interfaces/Ports
HDMI In Yes
HDMI Out Yes
Number of HDMI Inputs 1
Number of HDMI Outputs 16
Power Description
Input Voltage 12 V DC
Physical Characteristics
Height 1.6"
Width 5.9"
Length 18.1"
Weight (Approximate) 3.70 lb
Miscellaneous
Additional Information
  • HDMI version........................................................................................ HDMI 1.4b
  • HDCP version........................................................................................HDCP1.2
  • HDMI resolution ...............................up to 3840*2160/30Hz
  • Support video color format ................................................24bit/deep color 8/10/12bit
  • Support audio format...................DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
  • Max bandwidth........................................................................................320MHz
  • Max baud rate.........................................................................................3.2Gbps
  • Input/Output TMDS signal .........................................................0.5~1.5Volts p-p(TTL)
  • Input/Output DDC signal ................................................................. 5Volts p-p (TTL)
  • Input cable distance........ ..................................≤15m AWG26 HDMI 1.4standard cable 12m-4K
  • Output cable distance........................................≤25m AWG26 HDMI 1.4 standard cable  15m-4K
  • Max working current......................................................................................2.15A
  • Power adapter format..Input: ....................AC (50HZ, 60HZ) 100V-240V; Output: DC12V/5A
  • Operating Temperature range............................................................... (-15 to +55?)
  • Operating Humidity range.............................................5 to 90%RH (No Condensation)
Certifications & Standards
  • FCC
  • CE
Country of Origin China
Environmentally Friendly Yes
Warranty
Limited Warranty 1 Year
