We made the best better.
Datamax-O'Neil's I-Class revolutionized the barcode printer industry with its award winning modular design, field installable options and rugged reliability. For the past several years, resellers have named the I-Class the "best channel product" in some of the industry's largest third-party surveys. Now we've raised the bar even higher, with the redesigned I-Class Mark II.
| General Information | |
| Manufacturer | Honeywell International, Inc |
| Manufacturer Part Number | I12-00-4P040L07 |
| Manufacturer Website Address | http://www.honeywell.com |
| Brand Name | Datamax-O'Neil |
| Product Line | I-Class |
| Product Series | Mark II |
| Product Model | I-4212e |
| Product Name | I-Class Mark II I-4212e Label Printer |
| Product Type | Direct Thermal/Thermal Transfer Printer |
| Technical Information | |
| Recommended Use | Label Print |
| Print Color Capability | Monochrome |
| Maximum Mono Print Speed | 12 in/s |
| Maximum Print Resolution (dpi) | 203 |
| Maximum Print Width | 4.10" |
| Barcode Symbology Supported | UPC-E |
| Barcode Symbology Supported | Codabar |
| Barcode Symbology Supported | Telepen |
| Barcode Symbology Supported | Data Matrix |
| Barcode Symbology Supported | TLC 39 |
| Barcode Symbology Supported | Interleaved 2 of 5 |
| Barcode Symbology Supported | HIBC |
| Barcode Symbology Supported | POSTNET |
| Barcode Symbology Supported | Maxi Code |
| Barcode Symbology Supported | Aztec Code |
| Barcode Symbology Supported | Standard 2 of 5 |
| Barcode Symbology Supported | Code 11 |
| Barcode Symbology Supported | UPC 2 and 5 Digit Addendums |
| Barcode Symbology Supported | Code 16K |
| Barcode Symbology Supported | GS1 DataBar |
| Barcode Symbology Supported | FIM |
| Barcode Symbology Supported | PDF-417 |
| Barcode Symbology Supported | Codablock |
| Barcode Symbology Supported | Code 3 of 9 |
| Barcode Symbology Supported | Code 128 |
| Barcode Symbology Supported | Planet Code |
| Barcode Symbology Supported | Micro PDF-417 |
| Barcode Symbology Supported | EAN-8 |
| Barcode Symbology Supported | EAN-13 |
| Barcode Symbology Supported | Industrial 2 of 5 |
| Barcode Symbology Supported | UCC/EAN 128 |
| Barcode Symbology Supported | USPS-4 State |
| Barcode Symbology Supported | UPC-A |
| Barcode Symbology Supported | Plessey |
| Barcode Symbology Supported | USD-8 |
| Barcode Symbology Supported | QR Code |
| Barcode Symbology Supported | Code 93 |
| Real Time Clock | Yes |
| Application/Usage | Desktop |
| Features | Media Supply Hub |
| Features | Mirror Printing |
| Print Technology | Direct Thermal /Thermal Transfer |
| Memory | |
| Standard Memory | 32 MB |
| Memory Technology | SDRAM |
| Flash Memory | 64 MB |
| Interfaces/Ports | |
| Parallel Port | Yes |
| Serial Port | Yes |
| USB | Yes |
| Network & Communication | |
| Ethernet | Yes |
| Ethernet Technology | Fast Ethernet |
| Display & Graphics | |
| Display Screen | Yes |
| Display Screen Type | LCD |
| Cutter | |
| Cutter | Yes |
| Media Types & Handling | |
| Media Type | Ticket Stock |
| Media Type | Perforated Label |
| Media Type | Die-cut Label |
| Media Type | Black Mark |
| Media Type | Continuous Label |
| Media Type | Continuous Tag |
| Media Type | Roll Fed |
| Media Type | Shipping Label |
| Media Type | Fanfold |
| Media Sensor | Transmissive Media Sensor |
| Media Sensor | Reflective Media Sensor |
| Media Thickness | 10 mil |
| Maximum Roll Diameter | 8" |
| Maximum Label Width | 4.65" |
| Label Core Size | 3" |
| Ribbon Core Size | 1" |
| Fonts & Emulation | |
| Language Emulation | PLI |
| Language Emulation | DPL |
| Language Emulation | PLZ |
| Power Description | |
| Power Source | AC Supply |
| Input Voltage | 220 V AC |
| Input Voltage | 110 V AC |
| Physical Characteristics | |
| Height | 12.7" |
| Width | 12.6" |
| Depth | 18.6" |
| Weight (Approximate) | 45 lb |
| Miscellaneous | |
| Platform Supported | PC |
| Warranty | |
| Limited Warranty | 1 Year |
