Acrosser  Selector

Acrosser AR-V6100FLCM810 AR-V6100FL with Intel Celeron B810 1.6GHz, DDR3 2G pre-installed , CE/FCC class B/E-Mark

Mfg Part Number:  AR-V6100FLCM810
Image may not reflect the actual item.
Price: $1,031.97
Quantity:
Status: Active
No Sales Tax except these states
, PO and Wire.
Manufacturer Warranty Policy:

AR-V6100FL is a fanless in-vehicle computer features Intel Core i7 technology. AR-V6100FL adopts Acrosser?s expertise of design for in-vehicle applications. These designs include smart power management, high efficient thermal module, and diversity of integrated communication technology such as CAN bus, Wi-Fi, 3.5G wireless WAN, Bluetooth and GPS.
  • 1. Intel Celeron, Core i5 up to i7 Quad-core Processor
  • 2. One CAN 2.0A/2.0B Interface
  • 3. 1-Wire i-Button interface for Driver ID and Sensors
  • 4. 4x Digital Inputs and 4 Digital Outputs
  • 5. VGA/HDMI/DVI Dual Independent Video Outputs
  • 6. External Removable Anti-Vibration/Shock Disk Bay and CF socket
  • 7. Internal 3.5G, GPS, WiFi, Blue Tooth Modules (Optional)
  • 8. Combo connector to simplify touch monitor installation
    • Chassis
    Dimensions (WxDxH) 310mm x 195mm x 80mm
    System Fan Fanless
    Chassis Construction Aluminum with SECC
    MotherBoard
    Processor Brand Intel
    Processor Type Intel Celeron B810
    Frequency 1.6 GHz
    Cache Memory -
    Chipset HM65
    Memory Form Factor SO-DIMM
    Memory Included 2 GB
    Memory Max 8 GB
    Memory Type DDR3
    Storage
    SATA 2
    SD Card -
    Cfast -
    mSATA -
    Compact Flash 1
    Remote Monitoring
    IPMI -
    I/O Interface
    Interface Type Ethernet, USB, RS232, RS422/485, CAN, GPIO
    PS2 (KB/MS) -
    USB 2.0 4
    USB 3.0 -
    Ethernet 2 x RJ45 GBE LAN
    RS-232 1 x DB9
    RS-422/485 1 x DB9
    CAN-bus 1 x JST
    Wireless Optional
    Cellular Optional
    Special Function Slot -
    Display Type DVI, HDMI
    Resolution (VGA) -
    Resolution (DVI) -
    Resolution (HDMI) -
    Resolution (S-Video) -
    Digital I/O/Relay -
    GPIO 4 x GPI, 4 x GPO
    Audio 1 x Line-out, 1 x Mic-in
    Expansions
    PCIe Mini 2
    PCI -
    PCIe -
    PCI/104 -
    PCI/104 Plus -
    Power Input
    Power Input Type Single DC / Terminal Block
    Operating Supply Voltage Range 9V to 32V
    Power Consumption 80W
    Reliability
    Mounting -
    Operating Temp. Min. -20C to-15.01C
    Operating Temp. Max. 60C to 64.99C
    Operating Vibration -
    Shock during Operating -
    Standards and Certifications CE/FCC/E-Mark
