Moxa MGate 4101-MB-PBS-T 1-port Modbus to PROFIBUS Slave gateway, 12-48VDC, -40~75°C

MOXA Major Lines
Mfg Part Number:  MGate 4101-MB-PBS-T
Image may not reflect the actual item.
Price: $944.38 + Free Shipping
Quantity:
Status: Active
No Sales Tax except these states
, PO and Wire.
Manufacturer Warranty Policy:
    Box Content includes:
  • CBL-RJ45F9-150: 1.5M 8-pin RJ45 to female DB9 RS-232 (DCE) cable for NP5600, NP5210, CP104JU

Check here for other accessories.

Related Model(s):

Moxa MGate 4101-MB-PBS      Out of Stock
1-port Modbus to PROFIBUS Slave gateway, 12-48VDC, 0~60°C

Specification

Power Requirements
Power Consumption MGate 4101-MB-PBS: 340 mA @ 12 VDC, 130 mA @ 48 VDC
MGate 4101I-MB-PBS: 375 mA @ 12 VDC, 140 mA @ 48 VDC
Input Voltage 12 to 48 VDC
Power Connector Terminal block
Software
Utilities MGate Manager for Windows 98/ME/NT/2000, Windows XP/2003/Vista/2008/7 x86/x64
Operation Modes RTU Slave, RTU Master, ASCII Slave, ASCII Master
Configuration Options Serial Console, Windows Utility
Bonus Features QuickLink, Paging
PROFIBUS Interface
Protocol PROFIBUS DP-V0 Slave
Data Rate 9600 bps to 12 Mbps
Connector DB9 female
Isolation Built-in (2KV)
Number of Ports 1
DIP Switch For Termination
Rotary Switch PROFIBUS address 0-99 (address 100-125 supported through software configuration)
Environmental Limits
Operating Temperature Standard Models: 0 to 60°C (32 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity 5 to 95% (non-condensing)
Physical Characteristics
Weight 500 g
Dimensions 36 x 105 x 140 mm (1.42 x 4.13 x 5.51 in)
Housing Metal
Reliability
MTBF (mean time between failures) 513,139 hrs
Modbus Serial Interface
Flow Control RTS/CTS, DTR/DSR (RS-232 only)
Data Bits 7, 8
Parity None, Even, Odd, Space, Mark
Stop Bits 1, 2
Connectors DB9 male
Serial Standards RS-232/422/485, software selectable
RS-485 Data Direction Control ADDC® (automatic data direction control)
ESD Protection 15 KV for all signals
Number of Ports 1
Pull High/Low Resistor for RS-485 1 KΩ, 150 KΩ
Terminator for RS-485 120 Ω
Baudrate 50 bps to 921.6 Kbps
Serial Signals
RS-485-4w Tx+, Tx-, Rx+, Rx-, GND
RS-485-2w Data+, Data-, GND
RS-422 Tx+, Tx-, Rx+, Rx-, GND
RS-232 TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Standards and Certifications
EMI EN 55022 Class A, FCC Part 15 Subpart B Class A
Safety UL 60950-1, EN 60950-1
Shock IEC 60068-2-27
Vibration IEC 60068-2-6
EMS EN 55024,
EN 61000-4-2 (ESD) Level 3,
EN 61000-4-3 (RS) Level 3,
EN 61000-4-4 (EFT) Level 4,
EN 61000-4-5 (Surge) Level 3,
EN 61000-4-6 (CS) Level 3,
EN 61000-4-8,
EN 61000-4-11,
EN 61000-4-12
EMC CE, FCC
Freefall IEC 60068-2-23
Warranty
Warranty Period 5 years
Details See www.moxa.com/warranty
