| USB | |
| Compliance | USB 1.1/2.0 compliant |
| Upstream | 1 USB port, Type B connector |
| Downstream | UPort 204: 4 USB
ports, Type A connectors UPort 207: 7 USB ports, Type A connectors |
| Speed | 480 Mbps (Hi-Speed USB) and 12 Mbps (Full-Speed USB) |
| Supply Current | 500 mA max. per channel |
| Physical Characteristics: | |
| Housing | Polycarbonate (PC) |
| Dimensions | UPort 204: 70 x 35
x 120 mm (2.76 x 1.38 x 4.72 in) UPort 207: 80 x 35 x 185 mm (3.15 x 1.38 x 4.72 in) |
| Environmental Limits: | |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -20 to 75°C (-4 to 167°F) |
| Ambient Relative Humidity | 5 to 95% RH |
| Regulatory Approvals | EN61000-3-2, EN61000-3-3, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5,EN61000-4-6, EN61000-4-8, EN61000-4-11,EN61000-6-2, EN61000-6-4, FCC Part 15 Class A, UL508, LVD |
| Power Requirements: | |
| Input Voltage | 12 to 40 VDC external power |
| Power Consumption | UPort 204: 1210 mA
@ 12 VDC, 610 mA @ 24 VDC, 430 mA @ 36 VDC UPort 207: 2170 mA @ 12 VDC, 1070 mA @ 24 VDC, 730 mA @ 36 VDC |
| Warranty | |
| Warranty Period | 5 years |
| Power Requirements | |
| Power Consumption | UPort 204: 1210 mA @ 12 VDC, 610 mA @ 24 VDC, 430 mA @ 36 VDC UPort 207: 2170 mA @ 12 VDC, 1070 mA @ 24 VDC, 730 mA @ 36 VDC |
| Input Voltage | 12 to 40 VDC external power |
| Environmental Limits | |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -20 to 75°C (-4 to 167°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| MTBF (mean time between failures) | |
| Time | UPort 204: 1,577,573 hrs UPort 207: 1,059,201 hrs |
| Database | Telcordia (Bellcore), GB |
| Physical Characteristics | |
| Weight | (product only) UPort 204: 800 g (1.76 lb) UPort 207: 875 g (1.93 lb) |
| Dimensions | UPort 204: 70 x 35 x 120 mm (2.76 x 1.38 x 4.72 in) UPort 207: 80 x 35 x 185 mm (3.15 x 1.38 x 4.72 in) |
| Housing | Polycarbonate (PC) |
| USB Interface | |
| Speed | 480 Mbps (Hi-Speed USB) and 12 Mbps (Full-Speed USB) |
| Supply Current | 500 mA max. per channel |
| Compliance | USB 1.1/2.0 compliant |
| Downstream | UPort 204: 4 USB ports, Type A connectors UPort 207: 7 USB ports, Type A connectors |
| Upstream | 1 USB port, Type B connector |
| Standards and Certifications | |
| EMI | EN 61000-3-2, EN 61000-3-3, EN 61000-6-2, EN 61000-6-4, FCC Part 15 Subpart B Class A |
| Safety | UL 508, LVD |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11 |
| EMC | CE, FCC |
| Green Product | RoHS, CRoHS, WEEE |
| Warranty | |
| Warranty Period | 5 years |
| Details | See http://www.moxa.com/support/warranty.htm |
