ST124W StarTech.com 4 Port VGA Video Splitter - Wall Mountable

The ST124W 4 Port wall-mountable VGA Video Splitter offers outstanding quality and distance, allowing you to deliver high resolution VGA video from a single video source to up to four monitors simultaneously.

Supporting a maximum VGA video bandwidth of up to 250MHz and resolutions up to 1600 x 1200, the device is sure to deliver on image quality. The wall-mountable multi-display VGA video splitter is very simple to install, allowing you to locate screens up to 65m (210ft) away from the VGA video source.

The video splitter provides versatile installation options, with top-side connection ports the unit can lay flat on or under your workspace , or you have the option to mount the splitter on a wall making it easy to position the VGA splitter as needed. A scalable video splitting solution, the device also allows you to cascade the signal using two additional splitters for broadcast from a single VGA source to up to 64 VGA monitors.

Typical applications of this product would include digital signage, retail and tradeshow environments, educational and government facilities, or corporate displays where high quality multi-monitor VGA video is required.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

More from the Manufacturer

More from the Manufacturer

General Information
Manufacturer	StarTech.com
Manufacturer Part Number	ST124W
Manufacturer Website Address	http://www.startech.com
Brand Name	StarTech.com
Product Model	ST124W
Product Name	4 Port Wall Mount VGA Video Splitter
Packaged Quantity	1
Product Type	Video Switchbox
Technical Information
Connectivity Technology	Cable
Number of Input Devices Supported	1
Device Supported	Computer
Number of Displays Supported	4
Video
Graphics Modes	UXGA
Maximum Video Resolution	1600 x 1200
Interfaces/Ports
VGA In	Yes
VGA Out	Yes
Number of VGA Inputs	1
Number of VGA Outputs	4
Media & Performance
Maximum Operating Distance	200 ft
Physical Characteristics
Form Factor	Wall Mountable
Height	1.1"
Width	3.2"
Depth	4.1"
Weight (Approximate)	4.60 oz
Miscellaneous
Package Contents	4 Port Wall Mount VGA Video Splitter 1 x Power Adapter 1 x Instruction Manual
Environmentally Friendly	Yes
Warranty
Limited Warranty	2 Year

Distribute and deliver VGA video content with the Converge A/V four-port VGA video Splitter by StarTech.com. Allowing a single VGA video source to be displayed on four monitors simultaneously, the ST124W VGA Video Splitter is perfect for retail and tradeshow environments, as well as educational and government facilities, or corporate displays where high quality video is required. The ST124W supports resolutions up to 1600 x 1200 and can be wall-mounted for "out of the way" installation. The VGA Splitter lets you locate screens up to 200' away from your system, and offers easy plug and play installation that makes for a quicker setup. Rely on Converge A/V products for all your Audio/Visual and Digital Signage needs.

Device Type	Video splitter - cascadable
Enclosure Type	External
Width	3.4 in
Depth	4.5 in
Height	1.3 in
Enclosure Color	Silver
Networking
Ports Qty	4
Connectivity Technology	Wired
Status Indicators	Power
Features	Wall mountable
KVM
Max Cascading Depth	3
Max Resolution	1920 x 1440 @ 75 Hz
Max Video Bandwidth	250 MHz
Expansion / Connectivity
Interfaces	4 x display / video - VGA output - 15 pin HD D-Sub (HD-15) female
Connections	1 x display / video - VGA input - 15 pin HD D-Sub (HD-15) male
Miscellaneous
Compliant Standards	CE, FCC, RoHS
Power
Power Device	Power adapter - external
Power Consumption Operational	2.25 Watt
Manufacturer Warranty
Service & Support	1 year warranty
Service & Support Details	Limited warranty - 1 year
Environmental Parameters
Min Operating Temperature	32 °F
Max Operating Temperature	122 °F
Humidity Range Operating	0 - 80%
