The Advantech IDS-3119 Embedded Open Frame Monitor series offers flexible options for LCD, touchscreen, signal interface and chassis mounting. The series supports rear and VESA mounting. The integrated brackets bring the benefits of easy installation and provide flexibility for different applications.
| General Information | |
| Manufacturer | Advantech Co., Ltd |
| Manufacturer Part Number | IDS-3119N-35SXA1E |
| Manufacturer Website Address | http://www.advantech.com |
| Brand Name | Advantech |
| Product Model | IDS-3119 |
| Product Name | 19" SXGA 350nits Open Frame Monitor |
| Product Type | Open-frame LCD Monitor |
| Technical Information | |
| Number of Screens | 1 |
| Screen Size Class | 19" |
| Viewable Screen Size | 19" |
| Screen Mode | SXGA |
| Response Time | 5 ms |
| Horizontal Viewing Angle | 170° |
| Vertical Viewing Angle | 160° |
| Mount Type | Rear Mount |
| Backlight Technology | LED |
| Features | Anti-reflective |
| Features | Multi Language Display |
| Features | AutoTune |
| Features | On-screen Display (OSD) |
| Features | Power Switch |
| Glass Hardness | 3H |
| Video | |
| Maximum Resolution | 1280 x 1024 |
| Color Supported | 16.7 Million Colors |
| Native Contrast Ratio | 1,000:1 |
| Brightness | 350 Nit |
| Interfaces/Ports | |
| DVI | Yes |
| USB | Yes |
| VGA | Yes |
| Number of USB Ports | 1 |
| Number of DVI Ports | 1 |
| Number of VGA Ports | 1 |
| Physical Characteristics | |
| VESA Mount Compatible | Yes |
| Height | 14.6" |
| Width | 17.2" |
| Depth | 1.4" |
| Weight (Approximate) | 9.92 lb |
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 2 Year |
