PTZOPTICS
PT20X-STUDIO-4K-WH-G3 PTZOptics Studio 4K a Hive-Linked camera featuring 20X Optical Zoom up to a 4K Resolution at 60fps and a 67.8 DFOV 60.7 HFOV in white. Supports simultaneous outputs: HDMI2.0 or 3G-SDI plus IP Video [RTMP(S) SRT RTSP RTP] and either USB 3.0 or N
Mfg Part Number: PT20X-STUDIO-4K-WH-G3 , Item #: 5634450
, PO and Wire.
Connect, Point,Produce!
The Studio 4K features SDI, HDMI, USB, and IP output and comes native with NDI®HX2, allowing for seamless integration into various video production setups, connecting directly to a live production switcher, streaming over a network, or recording through an SDI interface. Built-in connectivity links to Hive Studio automatically!
Zoom In with Power and Endurance
The Studio 4K is your perfect entry into the world of 4K videography, offering powerful zoom capabilities and reliable performance. Capture a head-and-shoulders shot of your subject from up to 90 feet away with zoom strengths of 12X or 20X, ideal for medium or large spaces. Designed for utility and endurance, its unobtrusive design, continuous operation, and a variety of mounting options, the Studio 4K will be your new video system workhorse.
A Multitude of Applications
The Studio 4K is the perfect companion to a Move SE or Move 4K multi-camera setup, enhancing your production capabilities with an additional fixed-camera option that complements your PTZ cameras. The Studio 4K's high-quality construction and discreet profile makes it the perfect choice for streaming municipal meetings, worship services, sports, and security applications. In addition, as a fixed camera the Studio 4K is courtroom friendly.
Future-Friendly Performance
To accommodate ever-evolving productions, the Studio 4K is Hive-Linked, PTZOptics proprietary built-in automatic connection to Hive Studio, allowing centralized multi-camera control & management from anywhere within the comfort of a web browser. With just a few clicks, you'll have centralized management of all your cameras from anywhere with just a web connection, enabling controlling and configuring multiple cameras from a single interface-no need for complex multi-software setups.
Free Software for PTZOptics Users
PTZOptics cameras are compatible with a wide range of free software solutions, including:
Camera Management Platform (CMP) for camera management, control, color correction, and auto-tracking (zoom-only for the Studio 4K)
Control apps for desktop and mobile devices
Plugins and integrations for popular platforms, including OBS
Camera configuration and management tools
Support and testing utilities
And more!
Unrivaled Warranties
With robust warranties included standard on every product, you can trust PTZOptics solutions to deliver high performance from day one, and for many years to follow.
The Studio 4K comes with a 5-year limited parts and labor warranty. PTZOptics stands by our promise to protect your investment by providing repairs or replacement products for the duration of your warranty. For more information,
| General Information | |
| Manufacturer | PTZOptics |
| Manufacturer Part Number | PT20X-STUDIO-4K-WH-G3 |
| Manufacturer Website Address | http://www.ptzoptics.com |
| Brand Name | PTZOptics |
| Product Name | Studio 4K |
| Product Type | Network Camera |
| Technical Information | |
| Recording Formats | 4K |
| HD Recording | Yes |
| Night Vision | Yes |
| Night Vision Distance | 30 ft |
| Night Vision Type | Infrared |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/2.8" |
| Color Supported | Color |
| Field of View | H 3.5° ~ 60.7° | V 1.9° ~ 34.1° |
| Effective Camera Resolution | 8 Megapixel |
| Video | |
| Video Formats | H.264/AVC |
| Video Formats | H.264 |
| Video Formats | YUY2 |
| Video Formats | MJPEG |
| Video Formats | H.265 (HEVC) |
| Video Formats | H.265 |
| Maximum Video Resolution | 3840 x 2160 |
| Maximum Frame Rate | 60 fps |
| Analog Video Signal Format | 3G-SDI |
| Analog Video Signal Format | SDI |
| Analog Video Signal Format | NDI |
| Audio | |
| Audio Support | Yes |
| Lens | |
| Lens Type | Varifocal |
| Minimum Focal Length | 4.70 mm |
| Maximum Focal Length | 94 mm |
| Lens Included | Yes |
| Minimum Aperture | f/3.6 |
| Maximum Aperture | f/1.6 |
| Optical Zoom | 20x |
| Exposure | |
| Shortest Shutter Speed | 1/10000 Second |
| Longest Shutter Speed | 1/30 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Ethernet Technology | Gigabit Ethernet |
| Protocols | SRT |
| Protocols | ONVIF |
| Protocols | RTMP |
| Protocols | RTMPS |
| Protocols | RTSP |
| Protocols | UDP |
| Protocols | Multicast |
| Protocols | HTTP |
| Protocols | TCP/IP |
| Remote Management | Yes |
| Interfaces/Ports | |
| USB | Yes |
| HDMI | Yes |
| Network (RJ-45) | Yes |
| Power Description | |
| Maximum Power Consumption | 18 W |
| Input Voltage | 12 V DC |
| Power Source Type | DC |
| Power Source Type | PoE+ |
| Physical Characteristics | |
| Color Family | White |
| Product Color | White |
| Product Material | Aluminum |
| Product Material | Plastic |
| Height | 3.1" |
| Width | 3" |
| Length | 5.7" |
| Weight (Approximate) | 1.40 lb |
| Environmental Conditions | |
| Minimum Operating Temperature | 14°F (-10°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Minimum Operating Humidity | 10% |
| Maximum Operating Humidity | 80% |
| Miscellaneous | |
| Features | White Balance |
| Features | Auto Gain Control |
| Features | Auto Tracking |
| Features | Mirror |
| Indoor/Outdoor | Indoor |
| Warranty | |
| Limited Warranty | 5 Year |
