The SC-2702 27-inch surveillance monitor with BNC connector features 3-sided bezel-less specifically designed for security operators - especially those with a 24/7 operating multi-screen setup who are looking for efficient video monitoring. The SC-2702 provides value-added video enhancement controls that help create detailed images for low-light footage. Its optional monitor mounting solutions support single or multiple monitor setups. In terms of cost-to-performance, this model is the solution for productivity in modern operator workstations.
3-SIDED BEZEL LESS MONITOR INCREASE PRODUCTIVITY
The SC-2702 adopts a seamless 3-sided bezel-less design to create a productive work environment and reduce gaps between monitors. Perform rapid analysis, manage, and control video sources from all locations. Evolving situations require quick decisions, which seamless monitors can help with.
MULTIPLE MONITOR SETUPS MADE EASY
With VESA 100 x 100mm, the SC-2702 is compatible with AG Neovo's mounting portfolio of desk and wall mounts. Whether you're looking for a dual, quad, or more monitor set-up, AG Neovo is a one-stop-shop for creating ergonomic workstations in a control room.
HIGHER COST PERFORMANCE
Designed with long-hour monitoring in mind, you can expect a reduction in system maintenance efforts and consequentially higher cost performance. The SC-2702 is commercial grade and meant to work 24/7, 365 days a year. Static images that would otherwise cause screen burn-in are gone with AG Neovo's patented Anti-Burn-in technology. Expect prolonged life for LCD screens.
PERFECT MATCH TO CCTV IMAGES
There is a special pre-configured CCTV Mode that maximises image clarity in low-light footage. Quickly fine-tune your video footage with adjustments for sharpness, saturation, contrast, brightness, and more. Don't waste time testing and re-adjusting constantly, this product already has it all figured out!
ENHANCED GAMMA SELECTION
Offering an enhanced gamma selection makes for amazing visual optimization. Improve the light, shadow, and colour balance quality of your videos with ease.
MISSING DETAILS IN DARK SCENES IS A THING OF THE PAST
More detail from black-level adjustment means improved visibility of dark images.
CONTRAST ENHANCER
By coming with a contrast enhancer, the surveillance monitor enables low-contrast images to become more clear and defined.
ADAPTABLE TO SURVEILLANCE ENVIRONMENT NEEDS
Tailor the display to your needs with on/off toggles for the blue screen. When there is no signal available, a blue screen will show that is ideally designed for dark and low-light environments.
| General Information | |
| Manufacturer | AG Neovo Technology Corporation |
| Manufacturer Part Number | SC-2702 |
| Manufacturer Website Address | http://www.agneovo.com |
| Brand Name | AG Neovo |
| Product Series | SC |
| Product Model | SC-2702 |
| Product Name | SC-2702 27-Inch 1080p Monitor For Video Surveillance With BNC |
| Product Type | LCD Monitor |
| Technical Information | |
| Number of Screens | 1 |
| Screen Size Class | 27" |
| Viewable Screen Size | 27" |
| Screen Mode | Full HD |
| Panel Technology | Vertical Alignment (VA) |
| Response Time | 5 ms |
| Pixel Pitch | 0.31100 mm x 0.31100 mm |
| Horizontal Viewing Angle | 178° |
| Vertical Viewing Angle | 178° |
| Mount Type | Desk Mountable |
| Mount Type | Wall Mountable |
| Mount Type | Ceiling Mountable |
| Features | MultiScreen |
| Features | Cable Lock Slot |
| Features | Ergonomic Design |
| Features | Anti-glare |
| Features | Anti-Burn-in Technology |
| Features | Contrast Enhancer |
| Horizontal Frequency | 30 kHz to 85 kHz |
| Vertical Frequency | 48 Hz to 75 Hz |
| Stand Adjustments | Tilt |
| Glass Hardness | 3H |
| Operation Hours | 24 Hours/7 Days |
| Video | |
| Maximum Resolution | 1920 x 1080 |
| Color Supported | 16.7 Million Colors |
| Dynamic Contrast Ratio | 20,000,000:1 |
| Brightness | 300 Nit |
| Color Gamut | 72% NTSC |
| Audio | |
| Number of Speakers | 2 |
| Speakers | Yes |
| Interfaces/Ports | |
| HDMI | Yes |
| VGA | Yes |
| Number of HDMI Inputs | 1 |
| Number of VGA Ports | 1 |
| Power Description | |
| Frequency | 50 Hz |
| Frequency | 60 Hz |
| Physical Characteristics | |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 100 x 100 |
| Height | 14.4" |
| Width | 24.2" |
| Depth | 1.9" |
| Height with Stand | 17.87" |
| Width with Stand | 24.17" |
| Depth with Stand | 8.92" |
| Weight (Approximate) | 9.04 lb |
| Weight with Stand (Approximate) | 9.92 lb |
