Stand-alone 10 Gigabit Ethernet Media Converter
10GBase-T Copper to Fiber
The S4120 is a stand-alone media converter that provides an interface between 10GBase-T ports and 10GBase-X slot via an open SFP+ port, allowing users to convert their 10Gig Ethernet ports to the preferred type of cabling used in their networks. The open SFP+ slot supports a wide variety of Transition Networks 10GE SFP+ fiber modules. Operating at Layer 1, the physical layer, data is passed through the converter at line speed, making the S4120 ideal for applications where low latency is essential. The ION S4120 can be managed, in-band, over the fiber, when it is linked back to a C4120 card installed in a managed ION chassis.
General Information | |
Manufacturer | Lantronix, Inc |
Manufacturer Part Number | S41201048SA |
Manufacturer Website Address | http://www.lantronix.com |
Brand Name | Lantronix |
Product Line | ION |
Product Model | S4120-1048 |
Product Name | S4120-1048 Transceiver/Media Converter |
Product Type | Transceiver/Media Converter |
Interfaces/Ports | |
Total Number of Ports | 1 |
Network (RJ-45) | Yes |
Number of Network (RJ-45) Ports | 1 |
Media & Performance | |
Media Type Supported | Optical Fiber |
Media Type Supported | Twisted Pair |
Maximum Data Transfer Rate | 10 Gbit/s |
Maximum Distance Supported | 0.10 km |
I/O Expansions | |
Total Number of Expansion Slots | 1.0 |
Expansion Slot Type | SFP+ |
Number of SFP+ Slots | 1 |
Network & Communication | |
Ethernet Technology | 10 Gigabit Ethernet |
Network Technology | 10GBase-X |
Network Technology | 10GBase-T |
Power Description | |
Power Source | AC/DC |
Input Voltage | 12 V DC |
Power Consumption | 10.50 W |
Physical Characteristics | |
Form Factor | DIN Rail Mountable |
Form Factor | Standalone |
Form Factor | Rack-mountable |
Form Factor | Wall Mountable |
Form Factor | Shelf Mount |
Height | 1" |
Width | 3.3" |
Depth | 6.5" |
Weight (Approximate) | 2 lb |
Miscellaneous | |
Package Contents | |
Application/Usage | Network |
Application/Usage | Data |
Additional Information | 10GBase-T RJ-45 100m to 10GBase-X SFP+ Slot (Empty) |
Certifications & Standards | FCC Class A, EN55022 Class A, EN55024, CE Mark |
Environmentally Friendly | Yes |
Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
TAA Compliant | Yes |
NDAA Compliant | Yes |
Warranty | |
Limited Warranty | Lifetime |
