ESATAPLATE2 StarTech.com 2 Port SATA to eSATA Slot Plate Bracket

StarTech.com's eSATA SATA adapter plate adds external data support to any existing Serial ATA controller, adding two eSATA ports for connection to external SATA devices. The adapter plate can be mounted to the rear panel of the computer case, providing straightforward eSATA to SATA connections and allowing users to connect their eSATA device (hard drive enclosure, etc.) to the provided eSATA port which is an extension of the motherboard SATA data connector. Designed to take advantage of the increased data integrity provided by external hard drives or RAID devices that support eSATA connections, the eSATA SATA adapter supports data transfer rates of up to 6Gbps and is backed by StarTech.com's Lifetime Warranty. More from the Manufacturer

More from the Manufacturer

General Information
Manufacturer	StarTech.com
Manufacturer Part Number	ESATAPLATE2
Manufacturer Website Address	http://www.startech.com
Brand Name	StarTech.com
Product Name	SATA to eSATA Slot Plate Bracket
Packaged Quantity	1 Each
Product Type	Data Transfer Cable
Technical Information
Cable Type	eSATA/SATA
Cable Length	1 ft
Connector Type on First End	eSATA - Female
Connector on First End Details	2 x eSATA - Female
Connector Type on Second End	SATA - Male
Connector on Second End Details	2 x 7-pin SATA - Male
Conductor	Copper
Device Supported	RAID Controller
Device Supported	SATA Controller
Device Supported	Motherboard
Device Supported	Hard Disk Drive Enclosure
Device Supported	Computer
Device Supported	External Hard Drive
Data Transfer Rate	6 Gbit/s
Physical Characteristics
Color Family	Black
Product Color	Black
Weight (Approximate)	0.12 lb
Shipping Height	8.46"
Shipping Width	0.79"
Shipping Weight (Approximate)	2.08 oz
Miscellaneous
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Environmental Compliance	Waste Electrical and Electronic Equipment Directive (WEEE)
Environmental Compliance	Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Country of Origin	China
Warranty
Limited Warranty	Lifetime

Take the blazing speed of Serial ATA outside your case with an external slot plate from StarTech.com. The ESATAPLATE2 adds external data support to any existing Serial ATA controller. This product is designed to take advantage of the increased data integrity provided by external hard drives or RAID devices that support ESATA connections. You’ll get up to 300 MBytes/sec of reliable data transfer for your Serial ATA peripherals, like external storage devices.

Installation is easy: just install the plate into an open I/O slot on your computer and connect the cables to two Serial ATA connectors on your motherboard or controller card. The slim SATA data cable provides less clutter for increased airflow inside your case. Like all our cable products, the ESATAPLATE2 is backed by our lifetime warranty.

Specifications:

Warranty	Lifetime
Color	Red
Connector Types	2 - eSATA Plug
Connector Types	2 - SATA Data 7 pin Male
Carton Quantity	100
Length	12 inches
