CORE CLOCK
2588 MHz (Reference: 2452 MHz)
NVIDIA Blackwell Architecture The Ultimate Platform for Gamers and Creators
Fifth-Gen Tensor Cores
- Max AI performance with FP4 and DLSS 4
New Streaming Multiprocessors
- Optimized for neural shaders
Fourth-Gen Ray Tracing Cores
- Built for Mega Geometry
AI-Enhanced Graphics and Performance
- NVIDIA DLSS 4 with Multi Frame Generation
Game-Winning Responsiveness
- NVIDIA Reflex 2 with Frame Warp
True-to-Life Graphics
- Full ray tracing with neural rendering
Digital Humans and AI Assistants
- NVIDIA ACE
Accelerate Your Creativity
- NVIDIA Studio creator tools and technology
Enhance Any Video with AI
- NVIDIA Broadcast and ninth-gen NVIDIA Encoder
Performance and Reliability
- NVIDIA app with Game Ready and Studio Drivers
The Ultimate Gaming Display Technologies
- NVIDIA G-SYNC
WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system delivers exceptional thermal performance through a combination of cutting-edge technologies. It features server-grade thermal conductive gel, innovative Hawk fans with alternate spinning, composite copper heat pipes, a large vapor chamber, 3D active fans, and screen cooling.
| General Information | |
| Manufacturer | GIGABYTE Technology, Inc |
| Manufacturer Part Number | GV-N507TGAMINGOC16GD |
| Manufacturer Website Address | http://www.gigabyte.us |
| Brand Name | GIGABYTE |
| Product Model | GV-N507TGAMING OC-16GD |
| Product Name | GeForce RTX 5070 Ti GAMING OC 16G Graphic Card |
| Product Type | Graphic Card |
| Technical Information | |
| API Supported | OpenGL 4.6 |
| API Supported | DirectX 12 |
| Number of Monitors Supported | 4 |
| Features | Triple-fan Cooler |
| Maximum Digital Display Resolution | 7680 x 4320 |
| CUDA Cores | 8960 |
| AI-powered | Yes |
| Processor & Chipset | |
| Chipset Manufacturer | NVIDIA |
| Chipset Line | GeForce |
| Chipset Series | RTX |
| Chipset Model | RTX 5070 Ti |
| GPU Clock | 2.59 GHz |
| Memory | |
| Standard Memory | 16 GB |
| Memory Technology | GDDR7 |
| Bus Width | 256 bit |
| Interfaces/Ports | |
| Host Interface | PCI Express 5.0 |
| DisplayPort | Yes |
| Number of DisplayPort Outputs | 3 |
| HDMI | Yes |
| Number of HDMI Outputs | 1 |
| VGA | Yes |
| Power Description | |
| Power Supply Wattage | 750 W |
| Power Connector | 3x 8-pin |
| Power Connector | 1x 16-pin |
| Physical Characteristics | |
| Form Factor | Plug-in Card |
| Cooler Type | Active Cooler |
| Height | 2.8" |
| Width | 5.5" |
| Length | 13.4" |
| Miscellaneous | |
| Package Contents |
|
| Platform Supported | PC |
| Warranty | |
| Limited Warranty | 4 Year |
