TP LINK
TP LINK TP-Link NT SG2428LP Omada 28-Port Gigabit Smart Switch with 16-PortPoE+ Retail
Mfg Part Number: SG2428LP , Item #: 5260393
Image may not reflect the actual item.
Price: $367.74
Quantity:
In Stock: 2
Last Updated: Dec 21, 2025
No Sales Tax except these states
, PO and Wire.
24× Gigabit Ports (16× PoE+), 4× Gigabit SFP Slots
150 W Total PoE Budget
Fanless Design for Silent Operation
Zero-Touch Provisioning
Centralized Management
Omada App
Static Routing
Traffic Separation
Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.
Multiple Application Scenarios |Surveillance
Works with IP Cameras
Conference Call
Works with IP Phones
Wi-Fi Coverage
Works with Access Points
Wired Connections
Works with Non-PoE Devices such as PCs and Printers
Main Specification
| General Information | |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | SG2428LP |
| Manufacturer Website Address | http://www.tp-link.com/us |
| Brand Name | TP-Link |
| Product Line | Omada |
| Product Model | SG2428LP |
| Product Name | Omada 28-Port Gigabit Smart Switch with 16-Port PoE+ |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Zero-Touch Provisioning (ZTP) |
| Features | DHCP Snooping |
| Features | Fanless |
| Interfaces/Ports | |
| Total Number of Network Ports | 24 |
| Modular | Yes |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet Network |
| Port/Expansion Slot Details | 4 x Gigabit Ethernet Expansion Slot |
| Port/Expansion Slot Details | 16 × Gigabit Ethernet PoE+ |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T |
| Network Technology | 1000Base-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP (mini-GBIC) |
| Number of SFP Slots | 4 |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3x |
| Networking Standards | IEEE 802.1x |
| Networking Standards | IEEE 802.1p |
| Networking Standards | IEEE 802.3at |
| Networking Standards | IEEE 802.3af |
| Networking Standards | IEEE 802.1Q |
| Networking Standards | IEEE 802.1ab |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 150 W |
| Input Voltage | 230 V AC |
| Input Voltage | 120 V AC |
| Frequency | 50 Hz |
| Frequency | 60 Hz |
| Power Source | Power Supply |
| Power Consumption | 184.70 W |
| Physical Characteristics | |
| Product Material | Metal |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Height | 1.7" |
| Width | 17.3" |
| Depth | 8.7" |
| Miscellaneous | |
| Package Contents |
|
| Application/Usage | Desktop |
| Application/Usage | Surveillance |
| Application/Usage | IP Phone |
| Application/Usage | Printer |
| Application/Usage | IP Camera |
| Application/Usage | Network |
| Application/Usage | Wireless Access Point |
| Certifications & Standards |
|
