NEXSYS is built on a promise that we've kept for over two decades - more than half the life of the company - that our power products are designed, engineered, and built for AV. It's one thing to say it, it's another thing to prove it. And our NEXSYS Online UPSs prove it, we promise. They are built with premium components to keep your AV systems running as smoothly as you'd expect.
| General Information | |
| Manufacturer | Legrand Group |
| Manufacturer Part Number | UPX-OL3000R-2 |
| Manufacturer Website Address | http://www.legrand.us |
| Brand Name | Middle Atlantic |
| Product Line | NEXSYS |
| Product Name | NEXSYS 3000VA Rack-Mountable UPS |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | NEMA L5-30P |
| Receptacle Type | NEMA L5-30R |
| Receptacle Type | NEMA 5-20R |
| Receptacle Detail | 1 x NEMA L5-30R |
| Receptacle Detail | 6 x NEMA 5-20R |
| Cord Length | 10 ft |
| Application/Usage | Equipment |
| Power Description | |
| Load Capacity (VA) | 3000 VA |
| Load Capacity (Watt) | 2700 W |
| Output Voltage | 110 V AC |
| Output Voltage | 120 V AC |
| Output Voltage | 127 V AC |
| Waveform Type | Pure Sine Wave |
| Management | |
| Alarm | Battery Replacement |
| Battery Information | |
| Hot Swappable | Yes |
| Replaceable Battery | Yes |
| Environmental Conditions | |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Height | 3.50" |
| Width | 19" |
| Depth | 22" |
| Form Factor | Rack-mountable |
| Weight (Approximate) | 64.20 lb |
| Miscellaneous | |
| Certifications & Standards |
|
| Energy Star | Yes |
| Energy Efficiency Certification | ENERGY STAR 2.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 3 Year |
