STARTECH NLBK-1F-CAT6A-PATCH 1ft CAT6a Ethernet Cable LSZH
Mfg Part Number: NLBK-1F-CAT6A-PATCH , Item #: 5241993
, PO and Wire.
Cat6a Ethernet Low-Smoke Zero-Halogen (LSZH) Shielded cables support Multi-Gigabit/Multi-speed 1/2.5/5Gbps/10Gbp connections. It offers robust protection against electromagnetic interference (EMI/RFI) and noise, ensuring a fast, safe, and reliable network.
Low-Smoke Zero-Halogen (LSZH) CAT6A Ethernet Cable
LSZH Cat6a Network Cables are more eco-friendly than PVC cables. In the event of a fire, LSZH cables produce low levels of corrosive fumes and smoke. Low levels of acrid combustion pollutants promote increased visibility, resulting in safe and quick building evacuations by staff and first responders.
100W Power over Ethernet (PoE++)
This high performance Ethernet cable complies with the IEEE 802.3bt-2018 standard. It supports 100W PoE++, providing ample power to Type 4 PoE devices.
RJ45 Connectors with Snagless Clips
The Cat6a cable features snag-less connectors. Snagless molded boots protect the tab/latch on each RJ45 connector. The boots prevent the cable from snagging during cable routing and/or installation into network devices.
The molded boots feature integrated strain reliefs that prevent sharp connector/cable angles at the termination points.
This product is backed for life, including free lifetime 24/5 multi-lingual technical assistance.
| General Information | |
| Manufacturer | StarTech.com |
| Manufacturer Part Number | NLBK-1F-CAT6A-PATCH |
| Manufacturer Website Address | http://www.startech.com |
| Brand Name | StarTech.com |
| Product Name | Cat6a Ethernet Cable - LSZH |
| Packaged Quantity | 1 |
| Product Type | Network Cable |
| Technical Information | |
| Cable Type | Category 6a |
| Cable Characteristic | Patch Cable |
| Cable Length | 1 ft |
| Connector Type on First End | RJ-45 Network - Male |
| Connector Gender on First End | Male |
| Connector on First End Details | 1 x RJ-45 Network - Male |
| Connector Type on Second End | RJ-45 Network - Male |
| Connector Gender on Second End | Male |
| Connector on Second End Details | 1 x RJ-45 Network - Male |
| Contact Plating | Gold |
| Shielding | Yes |
| Jacket Type | LSZH |
| Device Supported | PoE Device |
| Device Supported | Network Device |
| American Wire Gauge | 27 AWG |
| Data Transfer Rate | 10 Gbit/s |
| Number of Conductors | 8 |
| Boot Type | Snagless |
| Boot Type | Molded |
| Number of Pairs | 4 |
| Features | Braided |
| Features | Strain Relief |
| Features | Noise Protection |
| Features | EMI/RF Protection |
| Features | Latch Protection |
| Features | Stranded |
| Features | PoE++ |
| Features | PoE |
| Features | Shielded with Foiled Twisted Pair (S/FTP) |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Product Material | Copper |
| Material Details | Conductor - Copper |
| Height | 0.6" |
| Width | 0.5" |
| Weight (Approximate) | 0.04 lb |
| Warranty | |
| Limited Warranty | Lifetime |
WARNING:: The plastic used in cable products can expose you to lead and lead components,
chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
For more information go to www.P65Warnings.ca.gov
