HPE
JL727B#B2B HPE Aruba Networking 6200F 48G CL4 4SFP+370W SW PDU
Mfg Part Number: JL727B#B2B , Item #: 5238968
Image may not reflect the actual item.
Price: $8,436.88
Quantity:
In Stock/Mfg Direct Ship
Last Updated: Apr 30, 2026
No Sales Tax except these states
, PO and Wire.
- Enterprise-class connectivity with support for ACLs, robust QoS, and common protocols such as static and Access OSPF routing.
- Scalability with 8 member VSF stacking. 24 and 48-port fixed and modular switch models can stack together for up to 384 ports.
- Models include modular switches with 1/10GbE uplinks, LRM, and MACSec 256, fixed switches with either 1/10GbE SFP+ or 1GbE SFP uplinks, and options that support 30W to 60W of PoE per port.
- Intelligent monitoring and visibility via Aruba Network Analytics Engine. Aruba NetEdit support for automation, configuration and verification. One touch deployment using the Aruba CX Mobile App.
- Aruba Dynamic Segmentation enables enhanced security and simple access for users and IoT.
- Flexible, modular switch models support hot-swappable, redundant power supplies and fans for enhanced resiliency.
Main Specification
| General Information | |
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | JL727B#B2B |
| Manufacturer Website Address | http://www.hpe.com |
| Brand Name | Aruba |
| Product Series | CX 6200 |
| Product Name | CX 6200 Ethernet Switch |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Hot-swappable |
| Interfaces/Ports | |
| Total Number of Network Ports | 48 |
| Uplink Port | Yes |
| Modular | Yes |
| Stack Port | Yes |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 1 x RJ-45 Console Port |
| Port/Expansion Slot Details | 1 x OOBM Port |
| Port/Expansion Slot Details | 48 x 10/100/1000BASE-T Gigabit Ethernet PoE+ RJ-45 Network Port |
| Port/Expansion Slot Details | 1 x USB Type-A Host Port |
| Port/Expansion Slot Details | 4 x 1/10 Gigabit Ethernet SFP Expansion Slot |
| Port/Expansion Slot Details | 1 x USB-C Console Port |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Optical Fiber |
| Ethernet Technology | 10 Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-X |
| Network Technology | 10GBase-X |
| Network Technology | 10/100/1000Base-T |
| Maximum Data Transfer Rate | 1.25 GB/s |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP |
| Expansion Slot Type | SFP+ |
| Shared SFP Slot | Yes |
| Number of SFP+ Slots | 4 |
| Network & Communication | |
| Networking Standards | IEEE 802.3af |
| Networking Standards | IEEE 802.3at |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 370 W |
| Input Voltage | 230 V AC |
| Input Voltage | 120 V AC |
| Power Source | Power Supply |
| Power Source | AC |
| Redundant Power Supply Supported | Yes |
| Number of Power Supplies Installed | 1 |
| Power Consumption | 76 W |
| Physical Characteristics | |
| Product Material | Sheet Metal |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Height | 1.7" |
| Width | 17.4" |
| Depth | 12.9" |
| Weight (Approximate) | 11.24 lb |
| Miscellaneous | |
| Application/Usage | IoT Devices |
| Application/Usage | Network |
| Application/Usage | Campus |
| Application/Usage | Enterprise |
| Application/Usage | Data Center |
| Application/Usage | Branch Office |
| Application/Usage | Wireless Access Point |
