Easily capture and recording 4K60Hz resolution from any HDMI source such as Gaming PC (4K144Hz), Gaming console (4K120Hz), Media players or Set-top box while simultaneously viewing in the HDMI loopout for 4K144Hz / 4K120Hz, 1080p240Hz resolution, USB-C 10Gbps, VRR, Aluminum Housing, ESD Protection, TAA Compliant
Features
Easily capture and record 4K@60Hz HDMI live video with low latency via a USB-C device and up to 10Gbps date transfer, great for gaming, live streaming, training, meetings and more
4K120Hz / 4K144Hz Pass-through & 4K60Hz Capture
Experience lifelike gaming with 4K144Hz (PC) / 2K144Hz (PC) / 4K120Hz (console) / 1080p240Hz HDMI input and pass-through, seamless capture / recording HDMI signals through USB-C 10Gbps, resolution supports 4K60Hz / 4K30Hz HDR / 2K120Hz / 2K60Hz HDR / 1080p240Hz and so on, ensuring every detail is preserved with crystal clarity. Supports various resolution with downscaling and upscaling
Live and Party Chat
Built-in two 4-pole 3.5mm jacks enable connection with a controller and headset for game console party mode, easily control game and chat volume, simultaneous party chat & live commentary recording. One 4-pole 3.5mm cable included, no additional purchase required
Note:1)
macOS max capture: 4K30Hz; 2) 4K144Hz only works in 48G bandwidth, monitor must support 4K144Hz 48G bandwidth, if the monitor only supports 4K144Hz DSC mode, it won't work with 4K144Hz
General Information | |
Manufacturer | SIIG, Inc |
Manufacturer Part Number | CE-H28311-S1 |
Manufacturer Website Address | http://www.siig.com |
Brand Name | SIIG |
Product Name | 4K120Hz HDMI 2.1 Capture Device for Gaming and Streaming - 4K60Hz Capture - 4K 120Hz (Console) / 4K144Hz (PC) Loopout - USB-C 10Gbps - TAA Compliant |
Packaged Quantity | 1 |
Product Type | Video Capturing Device |
Technical Information | |
Functions | Video Game Streaming |
Functions | Video Game Capturing |
Maximum Resolution | 3840 x 2160 |
Screen Mode Supported | 4K |
Video Formats | MJPEG |
Video Formats | YUY2 |
Platform Supported | PC |
Audio Channels | 7.1 |
Supported Video Modes | 2160p |
Supported Video Modes | 1080p |
Device Supported | Media Player |
Memory | |
Memory Technology | GDDR5 |
Interfaces/Ports | |
Host Interface | HDMI |
USB | Yes |
USB Standard | USB 2.0 |
HDMI | Yes |
Number of HDMI Inputs | 1 |
Number of HDMI Outputs | 1 |
Audio Line In | Yes |
Audio Line Out | Yes |
Software | |
Operating System Supported | macOS |
Operating System Supported | Linux |
Operating System Supported | Windows |
Physical Characteristics | |
Color Family | Black |
Product Color | Black |
Height | 0.8" |
Width | 4.6" |
Depth | 2.7" |
Weight (Approximate) | 0.56 lb |
Miscellaneous | |
Package Contents |
|
Country of Origin | Taiwan |
TAA Compliant | Yes |
Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Warranty | |
Limited Warranty | 3 Year |
