TP LINK
TP LINK TP-Link NVR VIGI NVR1004H-4P-2TB 4Channel PoE Network Video Recorder 2TB
Mfg Part Number: VIGI NVR1004H-4P-2TB , Item #: 5193926
Image may not reflect the actual item.
Price: $341.07
Quantity:
In Stock: 12
Last Updated: Sep 26, 2025
No Sales Tax except these states
, PO and Wire.
4 Channel PoE Network Video Recorder- Built in 2TB HDD SPEC: H.265+/H.265/H.264+/H.264, Up to 8MP resolution, Decoding capability/4-ch @4MP,80 Mbps Incoming Bandwidth(up to 4 channels),4× 10/100 Mbps PoE+ Ports, Max Output 53W, 802.3 af/at,1× SATA Interface(up to 10 TB, Built in 2TB HDD), 2× USB 2.0, 53.5V DC/1.31A, 1× VGA port & 1× HDMI port(Up to 4K)(Synchronous Outputs) FEATURE: Auto Initialization, Smart Detection Configuration & Alarm, Two-Way Audio, Simultaneous Playback, ONVIF, Remote Monitoring, VIGI App, Web, VIGI Security Manager
Main Specification
| General Information | |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | VIGI NVR1004H-4P-2TB |
| Manufacturer Website Address | http://www.tp-link.com/us |
| Brand Name | TP-Link |
| Product Line | VIGI |
| Product Model | NVR1004H-4P-2TB |
| Product Name | VIGI 4 Channel PoE+ Network Video Recorder |
| Product Type | Video Surveillance Station |
| Technical Information | |
| Total Number of Channels | 4 |
| Connectivity Technology | Wired |
| Recording Formats | 4K |
| HD Recording | Yes |
| System Components | Network Video Recorder |
| Features | Motion Detection |
| Storage | |
| Hard Drive Capacity | 2 TB |
| Video | |
| Video Formats | H.265 |
| Video Formats | H.265+ |
| Video Formats | H.264+ |
| Video Formats | H.264 |
| Maximum Resolution | 8MP |
| Maximum Frame Rate | 30 fps |
| Network & Communication | |
| Ethernet | Yes |
| Remote Management | Yes |
| Interfaces/Ports | |
| USB | Yes |
| USB Standard | USB 2.0 |
| Number of USB Ports | 2 |
| Total Number of Audio In Ports | 1 |
| Total Number of Audio Out Ports | 1 |
| Number of VGA Out | 1 |
| HDMI | Yes |
| Power Description | |
| Power Consumption | 13.10 W |
| Power Source | DC Supply |
| Physical Characteristics | |
| Height | 1.8" |
| Width | 9.7" |
| Depth | 5.8" |
| Environmental Conditions | |
| Minimum Operating Temperature | 14°F (-10°C) |
| Maximum Operating Temperature | 131°F (55°C) |
| Miscellaneous | |
| Package Contents |
|
