High-performance scanning for your document management solution
The DS-800WN is designed to be the perfect edge device for pulling digitized scan data into your document management solutions. EdgeLink™ scanners from Epson have built-in integrations with supported third-party software platforms. This allows end users to access their applications directly through the scanner's large 4.3" color touchscreen. For smaller businesses and organizations, Epson's powerful Document Capture Pro software is included, with features such as scanning to searchable PDF files. With accurate, high-quality scans at speeds up to 50 ppm/100 ipm and a 100-page Auto Document Feeder (ADF), the DS-800WN is engineered to bring speed, reliability and ease of use to your workflows. The scanner also supports ScanWay™ PC-free scanning, allowing you to scan to a USB flash drive, email, network folders or popular cloud services without the need to install any software. For implementations needing advanced administration, Epson offers a robust suite of optional solutions for the scanner that facilitate centralized management, reporting, and server-based capture and authentication (including Active Directory). Make document management work for you with the exceptional DS-800WN.
EdgeLink for supported document management solutions
Built-in direct integrations with supported third-party solutions
Intuitive touch panel
Easy-to-use, customizable 4.3" color LCD touchscreen for simple, mistake-free operation
Quickly scan two sides at once
One-pass duplex scanning at speeds up to 50 ppm/100 ipm; 100-sheet Auto Document Feeder (ADF)
Built for reliability
Engineered for heavy usage, with a peak daily duty cycle of up to 8,000 pages
Versatile connectivity
Built-in LAN and wireless networking and USB 3.2 Gen 1 connectivity allow for easy workgroup sharing
Document Capture Pro imaging software included
Provides powerful image enhancement and indexing options such as optical character recognition (OCR)
General Information | |
Manufacturer | Epson Corporation |
Manufacturer Part Number | B11B275201 |
Manufacturer Website Address | http://www.epson.com |
Brand Name | Epson |
Product Line | EdgeLink |
Product Series | DS |
Product Model | DS-800WN |
Product Name | DS-800WN EdgeLink Wireless Network Color Document Scanner |
Product Type | ADF Scanner |
Technical Information | |
Image Sensor Type | CIS |
Optical Resolution (dpi) | 600 |
Scan Color | Color |
Color Depth | 24-bit |
Grayscale Depth | 24-bit |
Maximum Mono Scan Speed (ppm) | 50 |
Maximum Color Scan Speed (ppm) | 50 |
Maximum Mono Scan Speed (ipm) | 100 |
Maximum Color Scan Speed (ipm) | 100 |
Media Type | ID Card |
Media Type | Plastic Card |
Media Type | Embossed Card |
Media Type | Business Card |
Media Type | Letter |
Media Size | - 2" x 2" |
Media Size | - 8.50" x 20 ft |
Media Size | - 8.50" x 17.92 ft |
Scanning Modes | Duplex |
ADF Capacity | 100 Sheets |
Duty Cycle | 8000 |
PC Free Scanning | Yes |
Duplex Scanning | Yes |
Light Source | RGB LED |
Network & Communication | |
Wireless LAN | Yes |
Interfaces/Ports | |
USB | Yes |
USB Standard | USB 3.2 |
Software | |
Operating System Supported | Windows Server 2022 |
Operating System Supported | Windows Server 2019 |
Operating System Supported | Windows 10 |
Operating System Supported | Windows Server 2016 |
Operating System Supported | Windows Server 2012 |
Operating System Supported | Windows 11 |
Operating System Supported | Windows Server 2012 R2 |
Operating System Supported | macOS 14.x |
Operating System Supported | macOS 10.14.x |
Power Description | |
Input Voltage | 230 V AC |
Input Voltage | 120 V AC |
Input Frequency | 60 Hz |
Input Frequency | 50 Hz |
Maximum Power Consumption | 15 W |
Ready-Mode Power Consumption | 5 W |
Physical Characteristics | |
Height | 6.6" |
Width | 11.7" |
Depth | 6.7" |
Weight (Approximate) | 8.20 lb |
Environmental Conditions | |
Minimum Operating Temperature | 41°F (5°C) |
Maximum Operating Temperature | 95°F (35°C) |
Miscellaneous | |
Package Contents |
|
Energy Star | Yes |
Country of Origin | Indonesia |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Warranty | |
Limited Warranty | 1 Year |
