Do you need to accelerate the performance of your mixed use applications?
HPE NVMe High Performance Read Intensive (RI) Enterprise and Datacenter Standard Form Factor (EDSFF) E3.S Solid State Drives (SSDs) are best suited for applications requiring a strong blend of high read IOPS, low latency, and high endurance at a strong price point. NVMe SSDs communicate directly to applications via the PCIe Gen 5 bus to boost I/O bandwidth and reduce latency.
HPE NVMe High Performance RI EDSFF E3.S SSDs replace the traditional 2.5 inch small form factor SSD while supporting greater density of NVMe drives. It provides high-performance data transfers at rates faster than SAS or SATA SSDs. Designed to utilize the high bandwidth of PCIe Gen 5 on servers with workloads high in reads such as read caching, web servers, and boot/swap.
Features
High Performance, Exceptional Reliability, and Efficiency for Faster Business Results
HPE NVMe Mainstream Performance Mixed Use Enterprise and Datacenter Standard Form Factor (EDSFF) E3.S Solid State Drives are ideal for Big Data analytics, cloud computing, high performance compute, business intelligence, database applications and virtualization.
Achieve higher IOPS to enhance the performance of your enterprise servers while maintaining data accuracy with full data-path error detection.
Improved thermals, power, and scalability provide better system efficiency for high I/O applications.
Faster PCIe Gen 5 technology is available with EDSFF E3.S SSDs.
Improved Design and Efficiency for Increased Performance on Gen 11 Servers
Dramatically increase density with a 1U server that can fit 20 E3.S or 10 E3.S 2T drives, or a 2U server that can fit 36 E3.S or 18 E3.S 2T drives.
Improve power management and density while utilizing less power.
| General Information | |
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | P70392-B21 |
| Manufacturer Website Address | http://www.hpe.com |
| Brand Name | HPE |
| Product Name | 3.84TB NVMe Gen5 High Performance Read Intensive E3S EC1 PS1010 SSD |
| Product Type | Solid State Drive |
| Technical Information | |
| Storage Capacity | 3.84 TB |
| Drive Performance | |
| Random 4KB Read | 1220136IOPS |
| Random 4KB Write | 320418IOPS |
| Endurance (DWPD) | 1.35 |
| Endurance Type | Read Intensive |
| Interfaces/Ports | |
| Drive Interface | PCI Express NVMe |
| Drive Interface Standard | PCI Express NVMe 5.0 |
| Physical Characteristics | |
| Drive Type | Internal |
| Form Factor | E3.S |
| Hot Pluggable | Yes |
| Height | 4.6" |
| Width | 7.9" |
| Depth | 10" |
| Weight (Approximate) | 1.19 lb |
| Miscellaneous | |
| Compatibility | HPE Gen 11 Servers |
| Device Supported | Data Center |
| Device Supported | Server |
