ALL-IN-ONE WINDOWS-BASED INTERACTIVE FLAT PANEL POWERED BY MAXHUB OS
The Windows-based MAXHUB XBoard provides seamless compatibility
ENHANCE YOUR MEETING EXPERIENCE WITH OUR INNOVATIVE AI-POWERED TRIDENT LENS SYSTEM
Equipped with three high-resolution 50-megapixel cameras-one for panoramic coverage and two with 2x optical zoom and 5x hybrid zoom-MAXHUB XBoard delivers a clear view of the meeting room and captures participants' expressions and nuances, fostering natural and focused communication in hybrid meetings. The AI system offers various viewing options, including room view, active speaker view, and individual participant views.
AUTO FRAMING
With auto-framing, the MAXHUB XBoard display automatically adjusts to achieve the best angle based on the number of participants and their location, so it feels like a face-to-face interaction.
SPEAKER TRACKING
Speaker-tracking technology locates the sound source in real-time, ensuring the speaker is always the center of attention. It supports two active speakers with a dual focus.
INTELLIGENT FOCUS
Intelligent focus technology enables individual close-ups for multiple participants simultaneously, delivering an immersive in-person experience.
AI NOISE REDUCTION
With 16 array microphones spanning a 180° wide-angle and boasting an 15-meter voice pickup range, coupled with its AI Noise Cancellation technology, the MAXHUB XBoard ensures crystal-clear voice transmission for all participants.
IMMERSE YOURSELF IN CRYSTAL CLEAR DETAIL WITH 4K DISPLAY TECHNOLOGY
With a 4K display four times more powerful than HD, every detail is brought to life with stunning clarity.
FLEXIBLE SIZES
The MAXHUB XBoard features 55/65/75/86-inch 16:9 resolution, offering great size and aspect ratio flexibility.
EFFICIENT, INSPIRED BRAINSTORMING
Start the whiteboard with just one click and dive into creative, efficient brainstorming. Equipped with 50 touch points, the device supports multiple people writing simultaneously and comes with a variety of preinstalled graphic templates.
CONTENT SHARING
Flexible content sharing with both wired and wireless options.
| General Information | |
| Manufacturer | MAXHUB |
| Manufacturer Part Number | V7550 |
| Manufacturer Website Address | http://www.maxhub.com |
| Brand Name | MaxHub |
| Product Line | XBoard |
| Product Series | V7 |
| Product Model | V7550 |
| Product Name | XBoard V7550 Collaboration Display |
| Product Type | Collaboration Display |
| Display & Graphics | |
| Screen Size | 75" |
| Display Screen Type | LCD |
| Display Screen Technology | Vertical Alignment (VA) |
| Backlight Technology | Direct LED |
| Screen Mode | 4K UHD |
| Screen Resolution | 3840 x 2160 |
| Scan Format | 2160p |
| Aspect Ratio | 16:9 |
| Response Time | 6.50 ms |
| Color Supported | 1.07 Billion Colors |
| Color Depth | 10-bit |
| Contrast Ratio | 5,000:1 |
| Display Orientation | Landscape |
| Brightness | 350 Nit |
| Horizontal Viewing Angle | 178° |
| Vertical Viewing Angle | 178° |
| Tempered Glass | Yes |
| Glass Thickness | 0.12" |
| Ambient Light Sensor | Yes |
| Standard Refresh Rate | 60 Hz |
| Touchscreen Information | |
| Touchscreen | Yes |
| Multi-touch Screen | Yes |
| Number of Touch Points | 50 |
| Touchscreen Technology | Infrared (IrDA) |
| Audio | |
| Speakers | Yes |
| Number of Speakers | 2 |
| Microphone | Yes |
| Number of Microphone Array Elements | 16 |
| RMS Output Power | 40 W |
| Camera | |
| Webcam | Yes |
| Network & Communication | |
| Ethernet | Yes |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Bluetooth | Yes |
| Bluetooth Standard | Bluetooth 5.2 |
| Interfaces/Ports | |
| HDMI | Yes |
| Number of HDMI Inputs | 2 |
| Total Number of USB Ports | 5 |
| Number of USB 2.0 Ports | 1 |
| Number of USB 3.0 Ports | 2 |
| USB | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Audio Line In | Yes |
| Audio Line Out | Yes |
| Serial | Yes |
| Software | |
| Operating System Platform | Windows |
| Operating System | MAXHUB OS 7.0 |
| Miscellaneous | |
| Package Contents |
|
| Energy Star | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
