Rigid Brass Housing + Fluid Dynamic Bearing = PERFECT
This IceGALE® fan has rigid brass housing that provides a reliable product and also has a fluid dynamic bearing to reduce noise levels so that it ensures a quiet operation.
Automatic START/STOP Function
Creates a quiet environment and reduces power consumption, decreasing heat, to create a more comfortable work/play experience. When the fan is in off mode it goes silent, until the PWM duty cycle reaches 21% loading.
Speeds Up to 1600 RPM
With a range from 500 RPM to 1600 RPM, this fan gives you the range to perform at a high-level with as little noise as possible.
Two-Plane Balance is Better Than One
Like any other IceGALE® fan from Iceberg Thermal, this fan comes equipped with two-plane balance to ensure stability in your fan.
Picking Up Bad Vibrations?
Our fans are designed with anti-vibration pads on the outer corners of the fans to absorb and eliminate vibrations so that your user experience is enhanced in a quiet environment.
Airflow Like No Other!
This fan gives you what you can't find anywhere else with 96 CFM airflow that will give your hardworking PC the breeze it deserves.
| General Information | |
| Manufacturer | Iceberg Thermal Inc. |
| Manufacturer Part Number | ICEGALE14-B0B |
| Manufacturer Website Address | https://www.iceberg-thermal.com |
| Brand Name | Iceberg |
| Product Line | IceGALE |
| Product Name | IceGALE 140 mm |
| Packaged Quantity | 1 |
| Product Type | Cooling Fan |
| Fan Information | |
| Number of Fans | 1 |
| Fan Bearing Type | Fluid Dynamic Bearing |
| Fan Speed (Min) | 500 rpm |
| Fan Speed (Max) | 1600 rpm |
| Maximum Airflow | 96 CFM |
| Noise Levels (A-Weighted) | 36 dB(A) |
| Fan Life | 17.1 Year |
| Maximum Air Pressure | 2.65mmH2O |
| Interfaces/Ports | |
| Connectors | 4-pin PWM |
| Power Description | |
| Rated Current | 230 mA |
| Physical Characteristics | |
| Color Family | Gray |
| Product Color | Gray |
| Maximum Fan Diameter | 5.51" |
| Fan Height | 0.98" |
| Fan Width | 5.51" |
| Miscellaneous | |
| Package Contents |
|
| Application/Usage | PC |
| Application/Usage | Case |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | 6 Year |
